[CHARGE UNIT]
S.=Surface mount
IC1 1190001180 S.IC MM1332BFBE
IC2 1180001160 S.IC S-80740SN-D4-T1
Q1 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q2 1590002880 S.FET 2SJ417-TL
Q3 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q4 1510000500 S.TRANSISTOR 2SA1162-GR (TE85R)
Q5 1510000500 S.TRANSISTOR 2SA1162-GR (TE85R)
Q6 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R)
D1 1790000670 S.DIODE SB07-03C-TB
D2 1730002540 S.ZENER MA8130-L (TX)
D3 1750000130 S.DIODE DA204U T107
D4 1730002460 S.ZENER MA8330-M (TX)
R1 7030000380 S.RESISTOR MCR10EZHJ 1 kΩ
R2 7030000140 S.RESISTOR MCR10EZHJ 10 Ω (100)
R3 7030000140 S.RESISTOR MCR10EZHJ 10 Ω (100)
R4 7030000530 S.RESISTOR MCR10EZHJ 18 kΩ
R5 7030000580 S.RESISTOR MCR10EZHJ 47 kΩ
R6 7030000420 S.RESISTOR MCR10EZHJ 2.2 kΩ
R7 7030000020 S.RESISTOR MCR10EZHJ 1 Ω (010)
R8 7030000020 S.RESISTOR MCR10EZHJ 1 Ω (010)
R9 7030000420 S.RESISTOR MCR10EZHJ 2.2 kΩ
R10 7030000420 S.RESISTOR MCR10EZHJ 2.2 kΩ
R11 7030000500 S.RESISTOR MCR10EZHJ 10 kΩ
R12 7030000570 S.RESISTOR MCR10EZHJ 39 kΩ
R13 7520000180 S.POSISTOR PTH9C32 BE 471Q-T
R14 7030000580 S.RESISTOR MCR10EZHJ 47 kΩ
R15 7030004490 S.RESISTOR MCR10EZHFX 12.1 kΩ
R16 7030002860 S.RESISTOR MCR10EZHFX 8.2 kΩ
R19 7030000570 S.RESISTOR MCR10EZHJ 39 kΩ
C1 4030004750 S.CERAMIC C2012 JB 1H 103K-T-A
C2 4510005380
ELECTROLYTIC 25 MV 47 HWS (5X11)
C3 4030004750 S.CERAMIC C2012 JB 1H 103K-T-A
C5 4510006160 ELECTROLYTIC 25 MV 10 HC
C6 4030004750 S.CERAMIC C2012 JB 1H 103K-T-A
C7 4030004750 S.CERAMIC C2012 JB 1H 103K-T-A
C8 4030004750 S.CERAMIC C2012 JB 1H 103K-T-A
C9 4030004720 S.CERAMIC C2012 JB 1H 102K-T-A
C10 4030004720 S.CERAMIC C2012 JB 1H 102K-T-A
J1 6450000410 CONNECTOR HEC0470-01-630
DS1 5040001390 LED TLG124A
W1 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W2 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W3 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W4 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W5 7030003970 S.JUMPER MCR18EZHJ JPW (000)
EP1 0910051992 PCB B 5392B
EP2 6910013110 SPACER TLE60-20
REF ORDER
DESCRIPTION
NO. NO.
7 - 3
D1
SB07-03C
Q1
2SD1664 Q
R1
1k
C1
0.01
D2
MA8130 L
J1
C2
47
W2
R2
10
R3
10
Q2
2SJ417
D3
DA204U
SW1
1
SW2
2
LV
3
GND
4
CS
5
CEL
6
EXT
7
VCC
8
IC1 MM1332B
C3
0.01
C5
10
R4
18k
W1
C10
0.001
C9
0.001
Q3
2SB1132 Q
D4
MA8330 M
R5
47k
R6
2.2k
MP1
+
MP2
BATV
MP3
–
R8
1
C8
0.01
R7
1
C6
0.01
R16
8.2k
C7
0.01
Q5
2SA1162 GR
Q6
2SC2712 GR
R14
47k
CP1
R19
39k
R15
12.1k
123
45
IC2
S-80740SN-D4
W4
W5
DS1
TLG124A
R11
10k
R10
2.2k
R9
2.2k
Q4
2SA1162 GR
R12
39k
R13
PTH9C32 BE 471Q-T
W3
NC
NC
VSS
VDD
OUT
CHARGER UNIT
E: 6.53V
F: 8.72V
E: 6.71V
F: 8.76V
E: 8.08V
F: 9.63V
E: 10.35V
F: 11.74V
E: 11.35V
F: 12.10V
E: 13.35V
F: 13.47V
E: 11.27V
F: 0V
E: 10.76V
F: 11.74V
E: 6.02V
F: 8.30V
E: 0.21V
F: 0.22V
E: EMPTY
F: FULL CHARGE
E: 6.10V
F: 8.35V
MP4 (C)
CHARGE unit
MP3 (C)
MP1 (CH)
MP2 (CH)
MP3 (CH)
MP2 (C)
MP1 (C)
MP7 (C)
MP5 (C)
MP6 (C)
MP6 (C)
MP5 (C)
(C) : CHASSIS
(CH) : CHARGE UNIT
NOTE:
• AD-95 VOLTAGE DIAGRAM
Screw abbreviations B0, BT: Self-tapping PH: Pan head
NI-ZU: Nickel-Zinc
MP1 8010018010 2329 Case 1
MP2 8930051060 2329 Lock plate 1
MP3 8810008660 Screw PH BT B0 3 × 8 NI-ZU 1
MP4 8110007040 2329 Cover 1
MP5 8810008660 Screw PH BT B0 3 × 8 NI-ZU 3
MP6 8930039620 Leg cushion (A) 2
REF ORDER
DESCRIPTION
NO. NO.
QTY.
[CHASSIS]
MP1 8930051050 2329 Terminal 1
MP2 8930051050 2329 Terminal 1
MP3 8930051050 2329 Terminal 1
REF ORDER
DESCRIPTION
NO. NO.
QTY.
[CHARGE UNIT]
• AD-95 CHARGER PARTS LIST
ELECTRICAL PARTS MECHANICAL PARTS
