6 - 4
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
DS240 5040003060 S.LED SML-512WWT86 T 53.1/3.8
DS241 5040003060 S.LED SML-512WWT86 T 61.1/3.8
DS242 5040003510 S.LED LNJ426W83RA T 17.2/32.2
DS243 5040003510 S.LED LNJ426W83RA T 28.1/32.2
DS244 5040003510 S.LED LNJ426W83RA T 17.2/18.5
DS245 5040003510 S.LED LNJ426W83RA T 28.1/18.5
DS246 5030003400 LCD TAK-35920 FX3340<ITAK>
DS247 5040003560 LED RT3-234HRH16T-BNS <ROD>
DS248 5040003001 S.LED SML-A12UT T86J T 2.9/25.3
MC250 7700002710 MIC EM6027P-46C33-G <HOR>
S250 2260001900 SWI SW-149 (SKHLLD)
EP2 6910014690 S.BEA MPZ1608S221A-T B 71.4/7.9
EP3 6910014690 S.BEA MPZ1608S221A-T B 88.1/12.7
EP8 6910021240 S.BEA MMZ1005A152ET B 61.1/17.0
EP10 6910014690 S.BEA MPZ1608S221A-T B 83.0/22.2
EP11 6910018460 S.BEA MMZ1005Y102C-T T 105.4/42.0
EP360 8930082550 LCD SRCN-3340-SP-N-W (SHJ)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
To Next Page
