Icom IC-M2A

S.=Surface mount
R500 7210003130 VARIABLE TP76N97N-13F-10KA-2497
EP500 0910055331 PCB B 5715A
IC1 1130007610 S.IC µPD3140GS-E1 (DS8)
IC50 1120002830 S.IC NJM2125F-TE1
IC170 1110003200 S.IC TA31136FN (EL)
IC190 1190000350 S.IC M62363FP-650C
IC200 1110003780 S.IC NJM2902V-TE1
IC220 1110005350 S.IC NJM2870F05-TE1
IC260 1140003830 S.IC TC4W66F (TE12L)
IC280 1110001810 S.IC TA7368F (TP1)
IC340 1130010390 S.IC HN58X2416TI
IC341 1130009110 S.IC S-80942ANMP-DD6-T2
IC360 1140010410 S.IC HD6433844RA60H (FX-2497A)
Q20 1590000430 S.TRANSISTOR DTC144EUA T106
Q21 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q22 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q23 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q24 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q25 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q50 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q51 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q52 1590002160 S.TRANSISTOR XP6401-(TX)
Q53 1560001020 S.FET 2SK2973 (MTS101P)
Q54 1560001050 S.FET 2SK2974
Q90 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q150 1580000660 S.FET 3SK272-(TX)
Q151 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q220 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q221 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q222 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q223 1590000430 S.TRANSISTOR DTC144EUA T106
Q224 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q225 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q230 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q231 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q240 1590001770 S.TRANSISTOR XP1213 (TX)
Q250 1590002530 S.TRANSISTOR UN911H (TX)
Q280 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q350 1590000660 S.TRANSISTOR DTC144TU T106
D1 1720000670 S.VARICAP HVU17TRF
D20 1790001260 S.DIODE MA2S077-(TX)
D21 1790000620 S.DIODE MA77 (TX)
D22 1720000780 S.VARICAP HVU350B TRF
D23 1720000780 S.VARICAP HVU350B TRF
D50 1790000620 S.DIODE MA77 (TX)
D51 1790000620 S.DIODE MA77 (TX)
D52 1790000580 S.DIODE 1SV307 (TPH3)
D80 1790001210 S.DIODE 1SS375-TL
D90 1790000580 S.DIODE 1SV307 (TPH3)
D91 1790001210 S.DIODE 1SS375-TL
D92 1790000620 S.DIODE MA77 (TX)
D93 1790000660 S.DIODE MA728 (TX)
D130 1790000620 S.DIODE MA77 (TX)
D350 1750000130 S.DIODE DA204U T106
FI150 2010002570 XTAL FL-346 (21.700 MHz)
FI151 2010002570 XTAL FL-346 (21.700 MHz)
FI170 2020001270 CERAMIC CFWLB450KE2A-B0 (CFWM450E)
X1 6050011350 S.XTAL CR-726 (21.250 MHz)
X170 6070000190
S.DISCRIMINATOR CDBCB450KCAY24-R0
X360 6050010290 S.XTAL CR-610 (7.9872 MHz)
L1 6200008070 S.COIL MLF1608E 6R8K 6.8U
L20 6200007000 S.COIL ELJRE 82NG-F
L21 6200003090 S.COIL NL 322522T-2R7J-3
L22 6200008190 S.COIL 0.25-1.9-8TL 80N
L23 6200006980 S.COIL ELJRE R10G-F
L24 6200006980 S.COIL ELJRE R10G-F
L25 6200006980 S.COIL ELJRE R10G-F
L49 6200005740 S.COIL ELJRE 47NG-F
L50 6200006980 S.COIL ELJRE R10G-F
L51 6200007000 S.COIL ELJRE 82NG-F
L52 6200010230 S.COIL EXCCL3216U1
L53 6200002330 S.COIL LQN 1A 15NJ04
L54 6200010230 S.COIL EXCCL3216U1
L55 6200009240 S.COIL 0.20-1.0-7TL 31N
L56 6200008530 S.COIL 0.30-1.0-4TL 12N
L57 6200008400 S.COIL 0.35-1.6-6TL 36N
L58 6200003710 S.COIL NL 252018T-2R7J
L80 6200008450 S.COIL 0.35-1.6-5TL 28N
L81 6200008450 S.COIL 0.35-1.6-5TL 28N
L82 6200008400 S.COIL 0.35-1.6-6TL 36N
L90 6200008150 S.COIL 0.35-1.6-7TL 44N
L91 6200007760 S.COIL LQN21A 82NJ04
L92 6200007760 S.COIL LQN21A 82NJ04
L93 6200008190 S.COIL 0.25-1.9-8TL 80N
L94 6200008190 S.COIL 0.25-1.9-8TL 80N
L95 6200004720 S.COIL MLF1608D R10K-T
L120 6200002430 S.COIL NL 252018T-082J
L121 6200002410 S.COIL NL 252018T-056J
L122 6200003550 S.COIL MLF1608A 4R7K-T
L130 6200007760 S.COIL LQN21A 82NJ04
L131 6200007760 S.COIL LQN21A 82NJ04
L132 6200008190 S.COIL 0.25-1.9-8TL 80N
L133 6200008190 S.COIL 0.25-1.9-8TL 80N
L150 6200003680 S.COIL LQN 1N R82M
R1 7510001160 S.THERMISTOR NTCCM1608 4LH 473KC
R2 7030003940 S.RESISTOR ERJ3GEYF 104 V (100 kΩ)
R3 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R4 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R5 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R6 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R7 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R8 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R9 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R10 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R20 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R22 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R23 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R24 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R25 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R26 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R27 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R28 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R29 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R30 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R31 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R32 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R33 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R34 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R35 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R36 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R50 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R52 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R53 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R54 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R55 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R56 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R57 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω)
R58 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R59 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[VR UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
