Icom IC-M32 Service Manual

[MAIN UNIT][MAIN UNIT]
IC1 1130007610 S.IC µPD3140GS-E1 (DS8) B
IC50 1120002830 S.IC NJM2125F-TE1 T
IC170 1110003200 S.IC TA31136FN (EL) B
IC190 1190000350 S.IC M62363FP-650C B
IC200 1110003780 S.IC NJM2902V-TE1 B
IC220 1110005350 S.IC NJM2870F05-TE1 T
IC260 1140003830 S.IC TC4W66F (TE12L) B
IC280 1110001810 S.IC TA7368F (ER) T
IC340 1130011540 S.IC BR24L16FV-WE2 B
IC341 1110006210 S.IC BD5242FVE-TR B
IC360 1140011630 S.IC M37560M8A-700GP (FX-2691A) B
Q20 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q21 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q22 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q23 1530002380 S.TRANSISTOR 2SC4215-Y (TE85R) B
Q24 1530002380 S.TRANSISTOR 2SC4215-Y (TE85R) B
Q25 1530002380 S.TRANSISTOR 2SC4215-Y (TE85R) B
Q50 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q53 1560001240 S.FET RD01MUS1 T
Q54 1560001230 S.FET RD07MVS1 T
Q90 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q150 1580000760 S.FET 3SK299-T1 U73 B
Q151 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R) T
Q220 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R) T
Q221 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R) T
Q222 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R) T
Q223 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q224 1590001190 S.TRANSISTOR XP6501-(TX) .AB B
Q225 1520000450 S.TRANSISTOR 2SB1132 T100 Q B
Q230 1520000450 S.TRANSISTOR 2SB1132 T100 Q T
Q231 1590001190 S.TRANSISTOR XP6501-(TX) .AB T
Q240 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q250 1590002530 S.TRANSISTOR UN911H (TX) B
Q280 1530003090 S.TRANSISTOR 2SC4213-B (TE85R) T
Q350 1590000660 S.TRANSISTOR DTC144TU T106 B
Q351 1590000720 S.TRANSISTOR DTA144EUA T106 T
D1 1750000770 S.VARICAP HVC376BTRF B
D20 1790001260 S.DIODE MA2S077-(TX) B
D21 1790000620 S.DIODE MA77 (TX) B
D22 1720000780 S.VARICAP HVU350B TRF B
D23 1720000780 S.VARICAP HVU350B TRF B
D50 1790000620 S.DIODE MA77 (TX) T
D51 1790000620 S.DIODE MA77 (TX) T
D52 1750000580 S.DIODE 1SV307 (TPH3) T
D80 1790001670 S.DIODE RB706F-40T106 T
D90 1750000580 S.DIODE 1SV307 (TPH3) B
D91 1790001670 S.DIODE RB706F-40T106 T
D92 1790000620 S.DIODE MA77 (TX) B
D93 1790000660 S.DIODE MA728 (TX) B
D130 1790000620 S.DIODE MA77 (TX) B
D350 1750000370 S.DIODE DA221 TL B
D353 1790000660 S.DIODE MA728 (TX) B
FI150 2030000350 MONOLITH 21R15AB (FL-368) B
FI151 2030000270 MONOLITH FL-363 (21.7 MHz) B
FI170 2020001270 CERAMIC CFWLB450KE2A-B0 B
X1 6050011740 S.XTAL CR-766 (21.250 MHz) B
X170 6070000190 S.DISCRIMINATOR CDBCB450KCAY24-R0 B
X360 6060010290 S.XTAL CR-610 (7.9872 MHz) B
L1 6200008070 S.COIL MLF1608E 6R8K 6.8U B
L20 6200007000 S.COIL ELJRE 82NG-F B
L21 6200003090 S.COIL NL 322522T-2R7J-3 B
L22 6200008190 S.COIL 0.25-1.9-8TL 80N B
L23 6200006980 S.COIL ELJRE R10G-F B
L24 6200006980 S.COIL ELJRE R10G-F B
L25 6200006980 S.COIL ELJRE R10G-F B
L50 6200006980 S.COIL ELJRE R10G-F T
L51 6200007000 S.COIL ELJRE 82NG-F T
L53 6200007690 S.COIL LQW2BHN18NJ01L T
L55 6200009240 S.COIL 0.20-1.0-7TL 31N T
L56 6200010640 S.COIL 0.26-1.0-3TL 8.5N T
L57 6200008230 S.COIL 0.30-1.3-5TL 22N T
S.=Surface mount
L58 6200003710 S.COIL NL 252018T-2R7J T
L80 6200008280 S.COIL 0.30-1.7-7TL 50N T
L81 6200009800 S.COIL 0.26-1.1-7TR 30N B
L82 6200008580 S.COIL 0.30-1.4-6TL 32N T
L90 6200008280 S.COIL 0.30-1.7-7TL 50N B
L91 6200007760 S.COIL LQW2BHN82NJ01L B
L92 6200007760 S.COIL LQW2BHN82NJ01L B
L93 6200008190 S.COIL 0.25-1.9-8TL 80N B
L94 6200008190 S.COIL 0.25-1.9-8TL 80N B
L95 6200006980 S.COIL ELJRE R10G-F B
L120 6200002430 S.COIL NL 252018T-082J T
L121 6200002410 S.COIL NL 252018T-056J T
L122 6200003550 S.COIL MLF1608A 4R7K-T B
L130 6200007760 S.COIL LQW2BHN82NJ01L B
L131 6200007760 S.COIL LQW2BHN82NJ01L B
L132 6200008190 S.COIL 0.25-1.9-8TL 80N B
L133 6200008190 S.COIL 0.25-1.9-8TL 80N B
L150 6200003680 S.COIL LQH31MNR82M01L B
R1 7510001660 S.THRMISTOR NTCG16 4LH 473KT B
R2 7030003940 S.RESISTOR ERJ3GEYF 104 V (100 kΩ) B
R3 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R4 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R5 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) B
R6 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R7 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R8 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R9 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R10 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R20 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R22 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) B
R23 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R24 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R25 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R26 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) B
R27 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) B
R28 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω) B
R29 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) B
R30 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) B
R31 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) B
R32 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) B
R33 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) B
R34 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R35 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) B
R36 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R50 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R52 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R53 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R54 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω) T
R55 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R56 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) T
R57 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω) T
R65 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R66 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R67 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R68 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R69 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R70 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R71 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R72 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R73 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R74 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R75 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R76 7030000280 S.RESISTOR MCR10EZHJ 150 Ω (151) T
R80 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R81 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R82 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R90 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R91 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R93 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R94 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R95 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R96 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) B
R100 7030003860 S.RESISTOR ERJ3GE JPW V T
R120 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R121 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R130 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R131 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R132 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R133 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
