Icom IC-M32 Service Manual

[MAIN UNIT]
R134 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω) B
R150 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R151 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) B
R152 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R153 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R154 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R155 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R156 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R170 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R171 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) B
R172 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R173 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R174 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R175 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R176 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) B
R192 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) B
R193 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R194 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R201 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) B
R202 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R203 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ) B
R204 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R205 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) B
R206 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) B
R207 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ) B
R212 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R213 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) B
R214 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) B
R220 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R221 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R222 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R223 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R224 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R225 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R226 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R227 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R228 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) B
R230 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ) T
R231 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R232 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R233 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R234 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R235 7030005930 S.RESISTOR ERJ3GEYF 334 V (330 kΩ) T
R236 7030008090 S.RESISTOR ERJ3EKF 1503 V (150 kΩ) T
R240 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R241 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) B
R242 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) B
R245 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R250 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R251 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R252 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R253 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R255 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) B
R256 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) B
R257 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R258 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R260 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) B
R261 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ) B
R262 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ) B
R263 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R264 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R265 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R271 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R272 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ) B
R273 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) B
R274 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ) B
R275 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R276 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ) B
R277 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R278 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R279 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω) B
R281 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) T
R282 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R283 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω) T
R284 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R286 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R288 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) T
R289 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R290 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R300 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) B
R304 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R305 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R340 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R341 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R343 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R345 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) B
R346 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R350 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) B
S.=Surface mount
6 - 2
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
R351 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R352 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) B
R353 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R360 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R361 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R362 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R363 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R364 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R366 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R367 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R371 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R372 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R373 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R374 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) B
R375 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) B
R376 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R377 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R378 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R379 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R380 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R381 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R382 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) T
R383 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) T
R384 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R385 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R386 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
C1 4030016930 S.CERAMIC ECJ0EB1A104K B
C2 4030016790 S.CERAMIC ECJ0EB1C103K B
C3 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C4 4030007040 S.CERAMIC C1608 CH 1H 180J-T B
C5 4030007030 S.CERAMIC C1608 CH 1H 150J-T B
C6 4030017460 S.CERAMIC ECJ0EB1E102K B
C7 4030016790 S.CERAMIC ECJ0EB1C103K B
C8 4030009520 S.CERAMIC C1608 CH 1H 020B-T B
C9 4030009520 S.CERAMIC C1608 CH 1H 020B-T B
C10 4030008920 S.CERAMIC C1608 JB 1H 473K-T B
C11 4550006560 S.TANTALUM ECST1CY225R B
C12 4030017460 S.CERAMIC ECJ0EB1E102K B
C20 4030017460 S.CERAMIC ECJ0EB1E102K B
C21 4030007000 S.CERAMIC C1608 CH 1H 090D-T B
C22 4030007000 S.CERAMIC C1608 CH 1H 090D-T B
C24 4030016930 S.CERAMIC ECJ0EB1A104K B
C25 4030017460 S.CERAMIC ECJ0EB1E102K B
C26 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C27 4030007080 S.CERAMIC C1608 CH 1H 390J-T B
C28 4030017460 S.CERAMIC ECJ0EB1E102K B
C29 4030017460 S.CERAMIC ECJ0EB1E102K B
C30 4030017460 S.CERAMIC ECJ0EB1E102K B
C31 4030017460 S.CERAMIC ECJ0EB1E102K B
C32 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T B
C33 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C34 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T B
C35 4030017460 S.CERAMIC ECJ0EB1E102K B
C36 4030017460 S.CERAMIC ECJ0EB1E102K B
C37 4030009570 S.CERAMIC C1608 CH 1H 0R3B-T B
C38 4030017460 S.CERAMIC ECJ0EB1E102K B
C39 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C40 4030007030 S.CERAMIC C1608 CH 1H 150J-T B
C41 4030017460 S.CERAMIC ECJ0EB1E102K B
C42 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C43 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C44 4030017460 S.CERAMIC ECJ0EB1E102K T
C50 4030017460 S.CERAMIC ECJ0EB1E102K T
C51 4030007050 S.CERAMIC C1608 CH 1H 220J-T T
C52 4030017460 S.CERAMIC ECJ0EB1E102K T
C53 4030017460 S.CERAMIC ECJ0EB1E102K T
C54 4030007030 S.CERAMIC C1608 CH 1H 150J-T T
C55 4030009650 S.CERAMIC C1608 CH 1H 240J-T T
C56 4030016790 S.CERAMIC ECJ0EB1C103K T
C57 4030016930 S.CERAMIC ECJ0EB1A104K T
C58 4030016930 S.CERAMIC ECJ0EB1A104K T
C59 4030017730 S.CERAMIC ECJ0EB1E471K T
C60 4030017460 S.CERAMIC ECJ0EB1E102K T
C61 4510006970 S.ELECTROLYTIC ECEV1CA330WR B
C62 4030017460 S.CERAMIC ECJ0EB1E102K T
C63 4030017730 S.CERAMIC ECJ0EB1E471K T
C64 4030017460 S.CERAMIC ECJ0EB1E102K T
C65 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C66 4030017460 S.CERAMIC ECJ0EB1E102K T
C67 4030017730 S.CERAMIC ECJ0EB1E471K T
C68 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C70 4030018020 S.CERAMIC C1608 CH 1H 910J-T T
C71 4030008560 S.CERAMIC C1608 CH 1H 300J-T T
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C73 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C74 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
REF ORDER
DESCRIPTION M.
NO. NO.
