Icom IC-M32 Service Manual

[MAIN UNIT][MAIN UNIT]
C75 4030007050 S.CERAMIC C1608 CH 1H 220J-T T
C80 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C81 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C82 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C83 4030007050 S.CERAMIC C1608 CH 1H 220J-T T
C84 4030011530 S.CERAMIC C1608 CH 1H 110J-T T
C85 4030009650 S.CERAMIC C1608 CH 1H 240J-T T
C86 4030007000 S.CERAMIC C1608 CH 1H 090D-T T
C87 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T T
C88 4030017460 S.CERAMIC ECJ0EB1E102K T
C89 4030006980 S.CERAMIC C1608 CH 1H 070D-T B
C90 4030007000 S.CERAMIC C1608 CH 1H 090D-T B
C91 4030007010 S.CERAMIC C1608 CH 1H 100D-T B
C92 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C93 4030009910 S.CERAMIC C1608 CH 1H 040B-T B
C94 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C95 4030007070 S.CERAMIC C1608 CH 1H 330J-T B
C96 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C97 4030009510 S.CERAMIC C1608 CH 1H 010B-T B
C98 4030017460 S.CERAMIC ECJ0EB1E102K B
C99 4030009520 S.CERAMIC C1608 CH 1H 020B-T B
C100 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C101 4030007070 S.CERAMIC C1608 CH 1H 330J-T B
C102 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C103 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C104 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C105 4030017460 S.CERAMIC ECJ0EB1E102K B
C106 4030017730 S.CERAMIC ECJ0EB1E471K B
C107 4030016790 S.CERAMIC ECJ0EB1C103K B
C108 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C109 4030017730 S.CERAMIC ECJ0EB1E471K B
C110 4030017460 S.CERAMIC ECJ0EB1E102K B
C120 4030016790 S.CERAMIC ECJ0EB1C103K T
C121 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C122 4030007030 S.CERAMIC C1608 CH 1H 150J-T T
C123 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C130 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C131 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C132 4030007070 S.CERAMIC C1608 CH 1H 330J-T B
C133 4030017990 S.CERAMIC MCH185A130JK B
C134 4030009510 S.CERAMIC C1608 CH 1H 010B-T B
C135 4030017460 S.CERAMIC ECJ0EB1E102K B
C136 4030017460 S.CERAMIC ECJ0EB1E102K B
C137 4030009520 S.CERAMIC C1608 CH 1H 020B-T B
C138 4030017990 S.CERAMIC MCH185A130JK B
C139 4030007070 S.CERAMIC C1608 CH 1H 330J-T B
C140 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C141 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C142 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C143 4030017460 S.CERAMIC ECJ0EB1E102K B
C150 4030017460 S.CERAMIC ECJ0EB1E102K B
C151 4030007100 S.CERAMIC C1608 CH 1H 560J-T B
C152 4030016970 S.CERAMIC ECJ0EB1C223K B
C153 4030017460 S.CERAMIC ECJ0EB1E102K B
C154 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C155 4030011770 S.CERAMIC C1608 CH 1H 060B-T T
C156 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C157 4030016970 S.CERAMIC ECJ0EB1C223K T
C158 4030017460 S.CERAMIC ECJ0EB1E102K T
C159 4030016790 S.CERAMIC ECJ0EB1C103K T
C160 4030018240 S.CERAMIC ECJ0EB1E562K T
C170 4030017460 S.CERAMIC ECJ0EB1E102K B
C171 4030007120 S.CERAMIC C1608 CH 1H 820J-T B
C174 4030017460 S.CERAMIC ECJ0EB1E102K B
C175 4030017460 S.CERAMIC ECJ0EB1E102K B
C176 4030017460 S.CERAMIC ECJ0EB1E102K B
C177 4030016930 S.CERAMIC ECJ0EB1A104K B
C178 4030011810 S.CERAMIC C1608 JB 1A 224K-T B
C179 4030007140 S.CERAMIC C1608 CH 1H 121J-T B
C180 4030007140 S.CERAMIC C1608 CH 1H 121J-T B
C181 4030016930 S.CERAMIC ECJ0EB1A104K B
C191 4030016790 S.CERAMIC ECJ0EB1C103K B
C192 4510004630 S.ELECTROLYTIC ECEV1CA100SR B
C193 4030016790 S.CERAMIC ECJ0EB1C103K B
C194 4030016790 S.CERAMIC ECJ0EB1C103K B
C200 4030016790 S.CERAMIC ECJ0EB1C103K B
C202 4030016930 S.CERAMIC ECJ0EB1A104K B
C205 4030016960 S.CERAMIC ECJ0EB1C183K B
C206 4030017460 S.CERAMIC ECJ0EB1E102K B
C207 4030016930 S.CERAMIC ECJ0EB1A104K B
C220 4510005430 S.ELECTROLYTIC ECEV0JA220SR B
C221 4030016790 S.CERAMIC ECJ0EB1C103K T
C222 4030016790 S.CERAMIC ECJ0EB1C103K T
C223 4030016790 S.CERAMIC ECJ0EB1C103K T
C224 4510005430 S.ELECTROLYTIC ECEV0JA220SR B
C225 4030011810 S.CERAMIC C1608 JB 1A 224K-T B
C226 4030016790 S.CERAMIC ECJ0EB1C103K T
C227 4550006710 S.TANTALUM ECST1AX226R B
S.=Surface mount
C228 4030017460 S.CERAMIC ECJ0EB1E102K T
C229 4030017460 S.CERAMIC ECJ0EB1E102K B
C230 4550006820 S.TANTALUM ECST1DX106R T
C231 4030008680 S.CERAMIC C2012 JF 1C 105Z-T T
C232 4030016930 S.CERAMIC ECJ0EB1A104K T
C233 4030016790 S.CERAMIC ECJ0EB1C103K T
C240 4030017460 S.CERAMIC ECJ0EB1E102K T
C250 4030016790 S.CERAMIC ECJ0EB1C103K B
C251 4510004630 S.ELECTROLYTIC ECEV1CA100SR B
C252 4030017460 S.CERAMIC ECJ0EB1E102K B
C254 4030016790 S.CERAMIC ECJ0EB1C103K B
C257 4030016790 S.CERAMIC ECJ0EB1C103K B
C260 4510004630 S.ELECTROLYTIC ECEV1CA100SR B
C261 4030016930 S.CERAMIC ECJ0EB1A104K B
C262 4030016790 S.CERAMIC ECJ0EB1C103K B
C263 4030016790 S.CERAMIC ECJ0EB1C103K B
C264 4030017780 S.CERAMIC ECJ0EB1E472K B
C265 4030007150 S.CERAMIC C1608 CH 1H 151J-T B
C266 4030017030 S.CERAMIC ECJ0EB1A273K B
C267 4030011810 S.CERAMIC C1608 JB 1A 224K-T B
C268 4030016930 S.CERAMIC ECJ0EB1A104K B
C280 4030017480 S.CERAMIC C1608 JB 1A 474K-T T
C281 4550006140 S.TANTALUM ECST1EY474R T
C282 4510004630 S.ELECTROLYTIC ECEV1CA100SR B
C283 4030016930 S.CERAMIC ECJ0EB1A104K T
C284 4030017460 S.CERAMIC ECJ0EB1E102K T
C285 4030016930 S.CERAMIC ECJ0EB1A104K T
C286 4550006200 S.TANTALUM ECST0JY106R T
C287 4030007150 S.CERAMIC C1608 CH 1H 151J-T T
C288 4030016950 S.CERAMIC ECJ0EB1A473K B
C289 4510005370 S.ELECTROLYTIC ECEV1AA221P B
C300 4030017770 S.CERAMIC ECJ0EB1E332K B
C340 4030016790 S.CERAMIC ECJ0EB1C103K B
C341 4030017030 S.CERAMIC ECJ0EB1A273K B
C350 4030016790 S.CERAMIC ECJ0EB1C103K B
C351 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C352 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C360 4030016790 S.CERAMIC ECJ0EB1C103K B
C361 4030016950 S.CERAMIC ECJ0EB1A473K B
C363 4030016950 S.CERAMIC ECJ0EB1A473K B
C364 4030016950 S.CERAMIC ECJ0EB1A473K B
C365 4030016950 S.CERAMIC ECJ0EB1A473K B
C366 4030016950 S.CERAMIC ECJ0EB1A473K B
C367 4030017040 S.CERAMIC ECJ0EB1A333K B
C368 4030016950 S.CERAMIC ECJ0EB1A473K B
C370 4030007040 S.CERAMIC C1608 CH 1H 180J-T B
C371 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C372 4030016930 S.CERAMIC ECJ0EB1A104K B
C373 4030016930 S.CERAMIC ECJ0EB1A104K B
C374 4030016930 S.CERAMIC ECJ0EB1A104K B
C375 4030016930 S.CERAMIC ECJ0EB1A104K B
C376 4030016930 S.CERAMIC ECJ0EB1A104K B
C377 4030009490 S.CERAMIC C1608 JB 1H 821K-T B
C378 4030017780 S.CERAMIC ECJ0EB1E472K B
C379 4030007100 S.CERAMIC C1608 CH 1H 560J-T B
C380 4030017460 S.CERAMIC ECJ0EB1E102K T
C381 4030017460 S.CERAMIC ECJ0EB1E102K T
C382 4030017460 S.CERAMIC ECJ0EB1E102K B
J250 6450001910 CONNECTOR HSJ1594-010150 B
J251 6510021900 S.CONNECTOR BM02B-ASRS-TF T
DS240 5040002660 S.LED FY1101F-TR (LED) T
DS241 5040002660 S.LED FY1101F-TR (LED) T
DS242 5040002310 S.LED SML-311YTT86 T
DS243 5040002310 S.LED SML-311YTT86 T
DS244 5040002310 S.LED SML-311YTT86 T
DS245 5040002310 S.LED SML-311YTT86 T
DS246 5030002600 LCD L3-0018TAY-1 T
MC250 7700002480 MICROPHONE SKB-2746 LPC T
S250 2260001900 SWITCH SW-149 (SKHLLD) B
S328 2260002710 S.SWITCH SKQLLCE012 B
EP1 0910056712 PCB B 6031B
EP2 6910014690 S.BEAD MPZ1608S221A-T T
EP3 6910014690 S.BEAD MPZ1608S221A-T T
EP360 8930057100 LCD CONTACT SRCN-2497-SP-N-W T
6 - 3
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
