Icom IC-M710

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
L122 6180001710 COIL LAL 03NA 561K
L123 6200003020 S.COIL NL 322522T-R33J-3
L124 6200003000 S.COIL NL 322522T-R22J-3
L125 6200003260 S.COIL NL 322522T-101J
L126 6180000990 COIL LAL 04NA 101K
L127 6200003260 S.COIL NL 322522T-101J
L129 6180000900 COIL LAL 03NA 101K
L130 6180000900 COIL LAL 03NA 101K
L131 6180000900 COIL LAL 03NA 101K
L132 6200003260 S.COIL NL 322522T-101J
L133 2040000490 COIL EXC-ELDR25C
L134 2040000490 COIL EXC-ELDR25C
L135 2040000490 COIL EXC-ELDR25C
L136 2040000490 COIL EXC-ELDR25C
L137 6200001720 S.COIL NL 322522T-1R0J
L138 2040000490 COIL EXC-ELDR25C
L139 6200001830 S.COIL NL 322522T-100J
L140 6200003260 S.COIL NL 322522T-101J
L141 2040000490 COIL EXC-ELDR25C
L142 6180000900 COIL LAL 03NA 101K
L143 2040000490 COIL EXC-ELDR25C
L144 6200003260 S.COIL NL 322522T-101J
L145 6200003260 S.COIL NL 322522T-101J
L147 6200003260 S.COIL NL 322522T-101J
L148 6200001710 S.COIL NL 322522T-220J
L149 6200003190 S.COIL NL 322522T-470J
R1 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R2 7010003180 RESISTOR ELR20J 15
Ω
R3 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R4 7010003200 RESISTOR ELR20J 22
Ω
R5 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R6 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R7 7010003390 RESISTOR ELR20J 820
Ω
R8 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R9 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R10 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R11 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R12 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R13 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R14 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R15 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R16 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R17 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R18 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R19 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R20 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R21 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R22 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R23 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R24 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R25 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R26 7310002670 S.TRIMMER RV-143 (RH03A3AS2) 471
R27 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R28 7010003350 RESISTOR ELR20J 390
Ω
R29 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R32 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150
Ω)
R33 7010003230 RESISTOR ELR20J 39
Ω
R34 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150
Ω)
R35 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R36 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R37 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R38 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R39 7010003180 RESISTOR ELR20J 15
Ω
R41 7010003240 RESISTOR ELR20J 47
Ω
R43 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 k
Ω)
R44 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47
Ω)
R45 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R46 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R47 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R48 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R49 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R50 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R51 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R52 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k
Ω)
R53 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R54 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R55 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R56 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R57 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R58 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R59 7010004450 RESISTOR R20J 100 kΩ
R60 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R61 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 k
Ω)
R62 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R63 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R64 7030006520 S.RESISTOR RR0816P-561-D (560
Ω)
R65 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47
Ω)
R66 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R67 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R68 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47
Ω)
R69 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R70 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R71 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R72 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R73 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R74 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47
Ω)
R75 7010003200 RESISTOR ELR20J 22
Ω
R76 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R77 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R79 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 M
Ω)
R80 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R81 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R82 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R83 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R84 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R85 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R86 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R87 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 k
Ω)
R88 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 k
Ω)
R89 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k
Ω)
R90 7510000290 THERMISTOR ERT-D2ZGL 301S
R91 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R92 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R94 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R95 7010003170 RESISTOR ELR20J 12
Ω
R96 7010003170 RESISTOR ELR20J 12 Ω
R97 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R98 7010003200 RESISTOR ELR20J 22
Ω
R99 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R100 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 k
Ω)
R101 7010003200 RESISTOR ELR20J 22
Ω
R102 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R103 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R104 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R105 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R106 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R107 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R108 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k
Ω)
R109 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k
Ω)
R110 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R111 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R112 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k
Ω)
R113 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k
Ω)
R114 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k
Ω)
R116 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R117 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R118 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R119 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω) [GEN]
R120 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω) [GEN]
R121 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R122 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R123 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R124 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R125 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R126 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R127 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R128 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R129 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100
Ω)
R130 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R131 7010003380 RESISTOR ELR20J 680
Ω
R132 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R133 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R134 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R135 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R136 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R138 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k
Ω)
R139 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R140 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R143 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R149 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R150 7010004270 RESISTOR R20J 4.7 k
Ω
R157 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k
Ω)
5 - 5
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[GEN]: [GEN-21], [GEN-22], [GEN-23] [EUR]: [EUR-21], [EUR-22]
[GMDSS]: [GEN-23], [EUR-22] [Others]: [GEN-21], [GEN-22], [EUR-21]
