[MAIN UNIT][MAIN UNIT]

S.=Surface mount

R158 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)

R159 7010004340 RESISTOR R20J 15 k

Ω

R161 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 M

Ω)

R162 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 M

Ω)

R163 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 M

Ω)

R164 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k

Ω)

R165 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k

Ω)

R166 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R167 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R168 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k

Ω)

R169 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k

Ω)

R170 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R171 7010003550 RESISTOR ELR20J 15 k

Ω

R172 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k

Ω)

R173 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R174 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k

Ω)

R175 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R176 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k

Ω)

R177 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R183 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k

Ω)

R184 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103

R185 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R186 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R187 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R188 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R189 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k

Ω)

R190 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R191 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R192 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R193 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R194 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R196 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R197 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R198 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R199 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)

R200 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R201 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R202 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 k

Ω)

R204 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R205 7310000660 TRIMMER RH0621C14J19A (103)

R207 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R208 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R209 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k

Ω)

R210 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150

Ω)

R211 7310002670 S.TRIMMER RV-143 (RH03A3AS2) 471

R212 7310002630 S.TRIMMER RV-139 (RH03A3A12) 101

R213 7510000240 THERMISTOR ERT-D2ZGL 332S

R214 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R215 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R216 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)

R217 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R218 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k

Ω)

R219 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R220 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470

Ω)

R221 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)

R222 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R223 7310002720 S.TRIMMER RV-148 (RH03A3AS3X0DA) 472

R224 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k

Ω)

R225 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R226 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470

Ω)

R227 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R228 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R229 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R230 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)

R231 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k

Ω)

R232 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k

Ω)

R233 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k

Ω)

R234 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R235 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)

R236 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k

Ω)

R237 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390

Ω)

R238 7310002710 S.TRIMMER RV-147 (RH03A3AN3X02A) 332

R239 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)

R240 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470

Ω)

R241 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k

Ω)

R242 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k

Ω)

R243 7010006930 RESISTOR PSD1/4 470

Ω

R244 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)

R245 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R246 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R247 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R254 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R255 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)

R256 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R257 7310000660 TRIMMER RH0621C14J19A (103)

R258 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k

Ω)

R259 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 M

Ω)

R261 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 M

Ω)

R262 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 M

Ω)

R263 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 M

Ω)

R264 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R265 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 k

Ω)

R266 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k

Ω)

R267 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 M

Ω)

R268 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47

Ω)

R269 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R270 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R271 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R272 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R273 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k

Ω)

R274 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R275 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R276 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R277 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220

Ω)

R278 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k

Ω)

R279 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R280 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330

Ω)

R281 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k

Ω)

R282 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k

Ω)

R283 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k

Ω)

R284 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R285 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R286 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k

Ω)

R287 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 k

Ω)

R288 7010003300 RESISTOR ELR20J 150

Ω

R290 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470

Ω)

R291 7030006520 S.RESISTOR RR0816P-561-D (560

Ω

)

R292 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k

Ω

)

R293 7030003560 .RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R294 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k

Ω)

R295 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R296 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)

R297 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R298 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100

Ω)

R299 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R300 7310000660 TRIMMER RH0621C14J19A (103)

R301 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k

Ω)

R302 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k

Ω)

R303 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R304 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k

Ω)

R305 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 M

Ω)

R306 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)

R307 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R308 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R310 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 k

Ω)

R324 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R325 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)

R328 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R329 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R333 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R334 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R335 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R336 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R337 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R338 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R339 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)

R340 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k

Ω)

R342 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R344 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R345 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R346 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)

R348 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R349 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R350 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470

Ω)

R352 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k

Ω)

R353 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470

Ω)

R354 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

R362 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k

Ω)

R363 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k

Ω)

R364 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)

R365 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k

Ω)

R369 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k

Ω)

R370 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 k

Ω)

R371 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k

Ω)

5 - 6

REF ORDER

DESCRIPTION

NO. NO.

REF ORDER

DESCRIPTION

NO. NO.

[GEN]: [GEN-21], [GEN-22], [GEN-23] [EUR]: [EUR-21], [EUR-22]

[GMDSS]: [GEN-23], [EUR-22] [Others]: [GEN-21], [GEN-22], [EUR-21]
