Icom IC-M710 - Page 28

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
R372 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R373 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k
Ω)
R374 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k
Ω)
R375 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R376 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R377 7010000090 RESISTOR ELR25J 4.7
Ω
R378 7010004190 RESISTOR R20J 1 k
Ω
R379 7010000090 RESISTOR ELR25J 4.7
Ω
R380 7010004190 RESISTOR R20J 1 k
Ω
R381 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R382 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k
Ω)
R383 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R385 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R386 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 k
Ω)
R387 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 k
Ω)
R388 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 k
Ω)
R389 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 k
Ω)
R390 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R391 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k
Ω)
R392 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R393 7010004690 RESISTOR R50XJ 47
Ω
R394 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47
Ω)
R395 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R396 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k
Ω)
R403 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R404 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R411 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R412 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R413 7010003280 RESISTOR ELR20J 100
Ω
R414 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R415 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R416 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R448 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R449 7010003180 RESISTOR ELR20J 15
Ω
R450 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R465 7010003200 RESISTOR ELR20J 22 Ω
R466 7010003200 RESISTOR ELR20J 22
Ω
R467 7010003200 RESISTOR ELR20J 22 Ω
R468 7010003200 RESISTOR ELR20J 22
Ω
R469 7010003200 RESISTOR ELR20J 22
Ω
R470 7010003200 RESISTOR ELR20J 22 Ω
R471 7010003200 RESISTOR ELR20J 22
Ω
R472 7010003200 RESISTOR ELR20J 22 Ω
R481 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R493 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R494 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R501 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R502 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R503 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R504 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R505 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R506 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k
Ω)
R510 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R514 7010000290 RESISTOR ELR25J 220
Ω
R515 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R517 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R518 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R519 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R520 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R521 7010003180 RESISTOR ELR20J 15 Ω
R522 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330
Ω)
R523 7010004690 RESISTOR R50XJ 47
Ω
R525 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R526 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R527 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R528 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k
Ω)
R529 7070000281 RESISTOR ERX1SJ 2R2 (2.2
Ω)
R533 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R534 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R535 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R536 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R537 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R538 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R539 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R540 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R541 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R542 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R543 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R544 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R545 7010004450 RESISTOR R20J 100 k
Ω
R601 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R602 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k
Ω)
R603 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R604 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k
Ω)
R605 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k
Ω)
R606 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 k
Ω)
R607 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k
Ω)
R608 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R609 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R610 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R611 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R612 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R633 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R634 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R635 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R636 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R637 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R638 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R639 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R640 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R641 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k
Ω)
R642 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R646 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R647 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R648 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k
Ω)
R650 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R651 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R652 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R653 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R654 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R655 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R657 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R658 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R659 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R663 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R664 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R670 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k
Ω)
R671 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R672 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R673 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R674 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R675 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R676 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R677 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R678 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R679 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R680 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R681 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R682 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R683 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R684 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R690 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R691 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R692 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R693 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R694 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R695 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R696 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R697 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10
Ω)
R698 7010003380 RESISTOR ELR20J 680 Ω
R699 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R700 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R701 7010007560 RESISTOR ERDS2TJ 1R0 (1
Ω)
R702 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470
Ω)
R703 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k
Ω)
R704 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k
Ω)
R705 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R706 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k
Ω)
R707 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220
Ω)
R708 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R709 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k
Ω)
R714 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R719 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
R720 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k
Ω)
R721 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R722 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R723 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 k
Ω)
R724 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R725 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R726 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k
Ω)
R729 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R730 7010003170 RESISTOR ELR20J 12
Ω
R731 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k
Ω)
R732 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k
Ω)
5 - 7
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[GEN]: [GEN-21], [GEN-22], [GEN-23] [EUR]: [EUR-21], [EUR-22]
[GMDSS]: [GEN-23], [EUR-22] [Others]: [GEN-21], [GEN-22], [EUR-21]
