REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[REC UNIT]
IC1 1130011980 S.IC BD5228G-TR T 12.2/15.2
IC2 1140012090 S.IC M30622M6P-131GP
(RX-2699A ALL) B 14.9/26.2
IC3 1130011681 S.IC FT245BL T 27.4/16.7
IC4 1130012250 S.IC SN74AHC1G02DCKR B 9.3/37.3
IC5 1130012260 S.IC SN74AHC1G32DCKR B 7.5/35.5
IC6 1130011971 S.IC K9F5608U0D-PCB0 <TOMO> B 24.2/12.2
IC7 1190001951 S.IC ML2302TBZ03A T 19.7/28.2
IC8 1130011801 S.IC SN74AHC1G66HDBV3 T 24.5/38.3
IC9 1130011801 S.IC SN74AHC1G66HDBV3 T 24.5/41.8
IC10 1180002371 S.REG R1111N321B-TR-F T 17.8/15.3
Q1 1590003301 S.TRA UNR921NG0L B 38.3/9.5
Q2 1590003511 S.TRA UNR9119G0L B 35.9/9.7
X1 6050010940 S.XTA CR-672 SMD-49 6.000 MHz
<KDS> T 7.4/13.9
X2 6050011240 S.XTA CR-708 DSX631S 16.384 MHz T 7.5/24.9
R1 7030005050 S.RES ERJ2GEJ 103 X (10K) T 11.2/19.5
R6 7030009530 S.RES ERJ2GEJ 270 X (27) T 35.4/12
R7 7030009530 S.RES ERJ2GEJ 270 X (27) T 35.9/13.5
R8 7030005240 S.RES ERJ2GEJ 473 X (47K) T 4.3/30
R9 7030005050 S.RES ERJ2GEJ 103 X (10K) T 12.7/18.7
R10 7030005240 S.RES ERJ2GEJ 473 X (47K) B 6.5/19.5
R11 7030005000 S.RES ERJ2GEJ 471 X (470) T 22/11.8
R12 7030007280 S.RES ERJ2GEJ 331 X (330) B 9.3/15.8
R13 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 34.6/13.4
R15 7030005240 S.RES ERJ2GEJ 473 X (47K) T 4.3/32
R16 7030005170 S.RES ERJ2GEJ 474 X (470K) T 28.3/33.6
R17 7030005100 S.RES ERJ2GEJ 154 X (150K) T 27.9/35.4
R18 7030005230 S.RES ERJ2GEJ 334 X (330K) T 46.1/46.6
R19 7030005240 S.RES ERJ2GEJ 473 X (47K) T 4.3/31
R20 7030004980 S.RES ERJ2GEJ 101 X (100) B 39.3/7.5
R21 7030005090 S.RES ERJ2GEJ 104 X (100K) T 8/31.4
R22 7030005090 S.RES ERJ2GEJ 104 X (100K) T 9.5/30.9
C1 4030016790 S.CER ECJ0EB1C103K T 32/10.5
C2 4550006050 S.TAN TEESVA 0J 106M8R T 15/14.8
C3 4030016790 S.CER ECJ0EB1C103K T 11.7/17.7
C4 4030016790 S.CER ECJ0EB1C103K T 17.3/17.7
C5 4030016790 S.CER ECJ0EB1C103K T 12.7/12.9
C6 4030017660 S.CER ECJ0EC1H330J B 7.9/16.6
C7 4030017660 S.CER ECJ0EC1H330J B 7.9/18
C8 4030017330 S.CER ECJ0EF1C104Z T 23.4/10.3
C9 4030017040 S.CER ECJ0EB1A333K T 35.9/15.7
C10 4030017330 S.CER ECJ0EF1C104Z B 10.7/15.1
C11 4030016790 S.CER ECJ0EB1C103K B 21.9/34.6
C12 4030016790 S.CER ECJ0EB1C103K B 6.4/18
C13 4030016790 S.CER ECJ0EB1C103K B 6/34.4
C14 4030016790 S.CER ECJ0EB1C103K B 13.9/4.1
C15 4030016790 S.CER ECJ0EB1C103K B 33.2/21.6
C16 4030016790 S.CER ECJ0EB1C103K T 28.9/31.4
C17 4030017390 S.CER ECJ0EC1H180J T 27.5/32.8
C18 4030016790 S.CER ECJ0EB1C103K T 21.6/40.8
C19 4030016790 S.CER ECJ0EB1C103K T 26/34.9
C20 4030017400 S.CER ECJ0EC1H220J T 10.3/22.7
C21 4030017400 S.CER ECJ0EC1H220J T 10.3/24.7
C22 4030016790 S.CER ECJ0EB1C103K T 19.7/38.7
C23 4030017490 S.CER C1608 JB 1A 105K-T T 14.4/35.5
C24 4030017490 S.CER C1608 JB 1A 105K-T T 16.4/37.5
C25 4030016790 S.CER ECJ0EB1C103K T 27.4/38.3
C26 4030016790 S.CER ECJ0EB1C103K T 27.4/41.8
C27 4550007460 S.TAN F930G107MBABMA B 35.3/5.6
C28 4030016790 S.CER ECJ0EB1C103K B 39.9/9.8
J2 6510024171 S.CON CSS5005-0401FSZ T 35.6/3.9
J6 6910006591 CON IMSA-9230B-1-04Z030-PT1
J7 6910006521 CON IMSA-9230B-1-06Z030-PT1
S1 2230001070 S.SWI JPM1990-2711R T 69.5/48.6
S2 2230001070 S.SWI JPM1990-2711R T 52.6/48.6
S3 2230001070 S.SWI JPM1990-2711R T 39.6/48.6
EP1 6910012350 S.BEA MMZ1608Y 102BT T 34/11.2
EP3 6910012350 S.BEA MMZ1608Y 102BT T 38.6/10.8
EP4 6910012350 S.BEA MMZ1608Y 102BT T 40.3/10.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
