[1STAVCO BOARD]
[1STAVCO BOARD]
IC2 1110005180 S.IC µPC2746TB-E3 B
IC3 1130011660 S.IC MB15T61ULPVA-G-ER B
Q1 1530003260 S.TRANSISTOR 2SC5006-T1 T
Q2 1530003260 S.TRANSISTOR 2SC5006-T1 T
Q3 1530003260 S.TRANSISTOR 2SC5006-T1 T
Q6 1560000530 S.FET 2SK880-GR (TE85R) B
Q7 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R) B
Q8 1530003580 S.TRANSISTOR 2SC5231C8-TL B
Q9 1530003580 S.TRANSISTOR 2SC5231C8-TL B
Q11 1590001810 S.TRANSISTOR XP1113 (TX) B
Q12 1590001810 S.TRANSISTOR XP1113 (TX) B
Q13 1530003590 S.TRANSISTOR 2SC5277D2-TL B
D1 1720000400 S.VARICAP 1SV245 (TPH3) T
D2 1720000400 S.VARICAP 1SV245 (TPH3) T
D3 1750001050 S.VARICAP HVC417CTRU T
D4 1750001050 S.VARICAP HVC417CTRU T
D7 1790001620 S.DIODE 1SV308 (TPL3) T
D8 1790001620 S.DIODE 1SV308 (TPL3) T
D9 1790001620 S.DIODE 1SV308 (TPL3) T
L1 6200009350 S.COIL ELJRE R22G-F3 T
L2 6200009350 S.COIL ELJRE R22G-F3 T
L3 6200010030 S.COIL C2012C-15NG T
L4 6200003960 S.COIL MLF1608A 1R0K-T T
L5 6200009350 S.COIL ELJRE R22G-F3 T
L6 6200009980 S.COIL C2012C-18NG T
L7 6200003960 S.COIL MLF1608A 1R0K-T T
L8 6200009350 S.COIL ELJRE R22G-F3 T
L9 6200009280 S.COIL
LQW18AN27NG00D (LQW1608A27NG00)
T
L10 6200003960 S.COIL MLF1608A 1R0K-T T
R1 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R2 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) T
R3 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R4 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ) T
R5 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) T
R6 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R7 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) T
R8 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R9 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ) T
R10 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) T
R11 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R12 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) T
R13 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R14 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ) T
R15 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω) T
R23 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R24 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ) B
R25 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) B
R26 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ) B
R27 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ) B
R28 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) B
R29 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R30 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) B
R31 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ) B
R32 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω) B
R33 7030007260 S.RESISTOR ERJ2GEJ 330 X (33 Ω) B
R34 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) B
R35 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ) B
R36 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R37 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R38 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R40 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R41 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω) B
R42 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) B
R43 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ) B
R44 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) B
R45 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
S.=Surface mount
R46 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R47 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R48 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R49 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ) B
R50 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R51 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R52 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R53 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) B
R54 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R55 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
[EUR], [UK], [USA], [CAN] B
7030010040 S.RESISTOR ERJ2GE-JPW
[SEA], [EXP-01], [EXP-02] B
R56 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
[EUR], [UK], [USA], [CAN] B
7030010040 S.RESISTOR ERJ2GE-JPW
[SEA], [EXP-01], [EXP-02] B
R57 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
[EUR], [UK], [USA], [CAN] B
7030010040 S.RESISTOR ERJ2GE-JPW
[SEA], [EXP-01], [EXP-02] B
C1 4030017460 S.CERAMIC ECJ0EB1E102K T
C2 4030017460 S.CERAMIC ECJ0EB1E102K T
C3 4030017360 S.CERAMIC ECJ0EC1H030B T
C4 4030017570 S.CERAMIC ECJ0EC1H040B T
C5 4030017460 S.CERAMIC ECJ0EB1E102K T
C6 4030016930 S.CERAMIC ECJ0EB1A104K T
C7 4030017530 S.CERAMIC ECJ0EC1H0R5B T
C8 4030016930 S.CERAMIC ECJ0EB1A104K T
C9 4030017460 S.CERAMIC ECJ0EB1E102K T
C10 4030017460 S.CERAMIC ECJ0EB1E102K T
C11 4030017350 S.CERAMIC ECJ0EC1H020B T
C12 4030017460 S.CERAMIC ECJ0EB1E102K T
C13 4030016930 S.CERAMIC ECJ0EB1A104K T
C14 4030017530 S.CERAMIC ECJ0EC1H0R5B T
C15 4030016930 S.CERAMIC ECJ0EB1A104K T
C16 4030017360 S.CERAMIC ECJ0EC1H030B T
C17 4030017460 S.CERAMIC ECJ0EB1E102K T
C18 4030017460 S.CERAMIC ECJ0EB1E102K T
C19 4030017600 S.CERAMIC ECJ0EC1H080C T
C20 4030017570 S.CERAMIC ECJ0EC1H040B T
C21 4030017460 S.CERAMIC ECJ0EB1E102K T
C22 4030016930 S.CERAMIC ECJ0EB1A104K T
C23 4030017530 S.CERAMIC ECJ0EC1H0R5B T
C24 4030016930 S.CERAMIC ECJ0EB1A104K T
C31 4030016790 S.CERAMIC ECJ0EB1C103K B
C35 4030017770 S.CERAMIC ECJ0EB1E332K B
C37 4550003220 S.TANTALUM TEESVA 1E 105M8L B
C38 4550000930 S.TANTALUM TEESVA 1D 684M8L B
C39 4550000930 S.TANTALUM TEESVA 1D 684M8L B
C40 4030016790 S.CERAMIC ECJ0EB1C103K T
C41 4030017460 S.CERAMIC ECJ0EB1E102K B
C42 4030017460 S.CERAMIC ECJ0EB1E102K B
C43 4030017350 S.CERAMIC ECJ0EC1H020B B
C44 4030017460 S.CERAMIC ECJ0EB1E102K B
C46 4030017460 S.CERAMIC ECJ0EB1E102K B
C47 4030017460 S.CERAMIC ECJ0EB1E102K B
C48 4340000290 S.MYLAR ECHU 1C 103JX5 B
C49 4030017620 S.CERAMIC ECJ0EC1H100C B
C50 4030017380 S.CERAMIC ECJ0EC1H050B B
C52 4030017460 S.CERAMIC ECJ0EB1E102K B
C53 4030017460 S.CERAMIC ECJ0EB1E102K B
C54 4030017460 S.CERAMIC ECJ0EB1E102K T
C55 4030017460 S.CERAMIC ECJ0EB1E102K T
C56 4030017460 S.CERAMIC ECJ0EB1E102K T
C58 4030016930 S.CERAMIC ECJ0EB1A104K B
C59 4030016790 S.CERAMIC ECJ0EB1C103K B
C60 4030016790 S.CERAMIC ECJ0EB1C103K B
C61 4030016930 S.CERAMIC ECJ0EB1A104K B
C62 4030016930 S.CERAMIC ECJ0EB1A104K B
C63 4030017460 S.CERAMIC ECJ0EB1E102K B
C64 4550007040 S.TANTALUM ECST0JZ106R B
C65 4550007040 S.TANTALUM ECST0JZ106R B
C66 4550007040 S.TANTALUM ECST0JZ106R B
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-1 IC-R20
