Icom IC-R20 Service Manual

5 - 7
SOFTWARE ADJUSTMENTS–Continued
S-METER
[S-M]
(2510.1 MHz
FM mode)
(2510.1 MHz
WFM mode)
21
22
• Mode : FM
• Connect an SSG to the antenna connector and set as
Level : 0.56 µV* (–112 dBm)
Frequency : 2510.1 MHz
Modulation : ±1 kHz
Deviation : ±3.5 kHz
• Receiving
• Mode : WFM
• Connect an SSG to the antenna connector and set as
Level : 32 µV* (–77 dBm)
Deviation : ±52.5 kHz
• Receiving
• Push [8 SET] key.
• Push [8 SET] key.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
*This output level of a standard signal generator (SSG) is indicated as SSG’s open circuit.

Icom IC-R20 Specifications

General

Mode	AM, FM, WFM, SSB, CW
Antenna Connector	BNC
Memory Channels	1250
Selectivity	AM/FM
Output Power	150mW at 8 Ohms
Battery Life	Approx. 8 hours with BP-206 (at 50mW audio output)
