[LOGIC UNIT][LOGIC UNIT]
Q28 1530003630 S.TRANSISTOR 2SC4617 TLS B
Q29 1590003290 S.TRANSISTOR UNR9213J-(TX) B
Q30 1520000650 S.TRANSISTOR 2SB1201-S-TL T
Q31 1590002950 S.FET HAT1023R-EL T
Q32 1530003630 S.TRANSISTOR 2SC4617 TLS T
Q33 1520000460 S.TRANSISTOR 2SB1132 T100 R T
Q34 1590003390 S.TRANSISTOR UNR9215J-(TX) T
Q35 1590003290 S.TRANSISTOR UNR9213J-(TX) T
Q36 1530003630 S.TRANSISTOR 2SC4617 TLS T
Q37 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R) B
Q38 1590001650 S.TRANSISTOR XP4601 (TX) B
D2 1790001240 S.DIODE MA2S728-(TX)
[SEA], [EXP-01], [EXP-02], [CAN] only B
D3 1750000940 S.DIODE ISS400 TE61 T
D5 1790001240 S.DIODE MA2S728-(TX) [USA] only B
D6 1750000940 S.DIODE ISS400 TE61 T
D8 1790001240 S.DIODE MA2S728-(TX) [UK], [USA] only B
D9 1750000940 S.DIODE ISS400 TE61 T
D11 1790001240 S.DIODE MA2S728-(TX) [EUR] only B
D12 1750000940 S.DIODE ISS400 TE61 T
D13 1750000940 S.DIODE ISS400 TE61 B
D14 1750000770 S.VARICAP HVC376BTRF B
D18 1720000600 S.VARICAP HN2V02H-B (TE12R) B
D20 1750000940 S.DIODE ISS400 TE61 B
D21 1750000940 S.DIODE ISS400 TE61 B
D22 1790001560 S.DIODE 1SS372 (TE85R) B
D23 1790001560 S.DIODE 1SS372 (TE85R) B
D24 1790001560 S.DIODE 1SS372 (TE85R) B
D25 1790001560 S.DIODE 1SS372 (TE85R) B
D26 1750000940 S.DIODE ISS400 TE61 T
D27 1750000940 S.DIODE ISS400 TE61 T
D28 1790001250 S.DIODE MA2S111-(TX) T
D29 1790000670 S.DIODE SB07-03C-TB T
D30 1750000940 S.DIODE ISS400 TE61 T
D31 1750000940 S.DIODE ISS400 TE61 T
D32 1790001250 S.DIODE MA2S111-(TX) B
D33 1730002510 S.ZENER MA8027-H (TX) B
D34 1790000670 S.DIODE SB07-03C-TB T
D35 1790001240 S.DIODE MA2S728-(TX) T
D36 1790000860 S.DIODE MA133 (TX) T
X1 6050011310 S.XTAL CR-717 (9.8304 MHz) B
X2 6060000820 S.CERAMIC CSBFB453KJ58-R1 B
L1 6200003640 S.COIL MLF1608E 100K-T B
R1 7410001110 S.ARRAY EXB28V332JX B
R2 7410001220 S.ARRAY EXB28V103JX B
R3 7410001220 S.ARRAY EXB28V103JX B
R4 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R5 7410001220 S.ARRAY EXB28V103JX B
R6 7410001220 S.ARRAY EXB28V103JX B
R7 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R8 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R9 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R10 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R11 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R12 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R13 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) B
R14 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R15 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R17 7410001220 S.ARRAY EXB28V103JX B
R18 7410001220 S.ARRAY EXB28V103JX B
R19 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R20 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R21 7410001110 S.ARRAY EXB28V332JX B
R22 7030010040 S.RESISTOR ERJ2GE-JPW B
R23 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R24 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R25 7410001110 S.ARRAY EXB28V332JX B
R26 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R27 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R28 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R29 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R30 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R31 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
S.=Surface mount
R32 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R33 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R34 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R35 7410001130 S.ARRAY EXB28V102JX B
R36 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R38 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R39 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R40 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R41 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R42 7410001130 S.ARRAY EXB28V102JX B
R43 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) B
R45 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R47 7030007320 S.RESISTOR ERJ2GEJ 225 X (2.2 MΩ) B
R49 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R51 7410001130 S.ARRAY EXB28V102JX B
R52 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R53 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R54 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R55 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω) T
R56 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R57 7030010040 S.RESISTOR ERJ2GE-JPW B
R58 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R59 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R60 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R61 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R62 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R63 7410001220 S.ARRAY EXB28V103JX B
R64 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) B
R66 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R67 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R68 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R69 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R70 7030010040 S.RESISTOR ERJ2GE-JPW B
R71 7030010040 S.RESISTOR ERJ2GE-JPW B
R72 7030010040 S.RESISTOR ERJ2GE-JPW B
R73 7030010040 S.RESISTOR ERJ2GE-JPW B
R74 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R76 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R77 7410001130 S.ARRAY EXB28V102JX B
R82 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R83 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R84 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R85 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R86 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R87 7030007350 S.RESISTOR ERJ2GEJ 393 X (39 kΩ) B
R88 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R89 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R90 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R91 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ) B
R93 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R94 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R95 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R96 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R97 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R98 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) B
R99 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R100 7030010040 S.RESISTOR ERJ2GE-JPW B
R101 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ) B
R103 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) B
R104 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R105 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ) B
R106 7030010040 S.RESISTOR ERJ2GE-JPW B
R107 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R108 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R110 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ) B
R111 7030010040 S.RESISTOR ERJ2GE-JPW B
R112 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) B
R113 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) B
R114 7030007320 S.RESISTOR ERJ2GEJ 225 X (2.2 MΩ) B
R115 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R116 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R117 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R118 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R119 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R120 7030009270 S.RESISTOR ERJ2GEJ 821 X (820 Ω) B
R121 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R122 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R123 7030009270 S.RESISTOR ERJ2GEJ 821 X (820 Ω) B
R124 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R125 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R126 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
6 - 6
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
