[RF UNIT][RF UNIT]
R539 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω) B
R540 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω) B
R541 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω) T
R542 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) T
C5 4030017730 S.CERAMIC ECJ0EB1E471K T
C12 4030017420 S.CERAMIC ECJ0EC1H470J B
C13 4030017650 S.CERAMIC ECJ0EC1H270J B
C14 4030017460 S.CERAMIC ECJ0EB1E102K B
C15 4030017340 S.CERAMIC ECJ0EC1H010B B
C16 4030017460 S.CERAMIC ECJ0EB1E102K B
C18 4030016790 S.CERAMIC ECJ0EB1C103K T
C22 4030017590 S.CERAMIC ECJ0EC1H070C T
C23 4030017380 S.CERAMIC ECJ0EC1H050B T
C27 4030017460 S.CERAMIC ECJ0EB1E102K T
C28 4030017460 S.CERAMIC ECJ0EB1E102K T
C30 4030017460 S.CERAMIC ECJ0EB1E102K T
C32 4030017460 S.CERAMIC ECJ0EB1E102K T
C40 4030017640 S.CERAMIC ECJ0EC1H150J T
C41 4030017380 S.CERAMIC ECJ0EC1H050B T
C42 4030017370 S.CERAMIC ECJ0EC1H3R5B T
C43 4030017430 S.CERAMIC ECJ0EC1H101J T
C44 4030016790 S.CERAMIC ECJ0EB1C103K T
C45 4030017730 S.CERAMIC ECJ0EB1E471K T
C46 4030017360 S.CERAMIC ECJ0EC1H030B T
C47 4030017580 S.CERAMIC ECJ0EC1H060C T
C48 4030017580 S.CERAMIC ECJ0EC1H060C T
C49 4030017360 S.CERAMIC ECJ0EC1H030B T
C50 4030017340 S.CERAMIC ECJ0EC1H010B T
C51 4030017560 S.CERAMIC ECJ0EC1H2R5B T
C52 4030017730 S.CERAMIC ECJ0EB1E471K T
C54 4030017460 S.CERAMIC ECJ0EB1E102K T
C55 4030017460 S.CERAMIC ECJ0EB1E102K T
C58 4030017460 S.CERAMIC ECJ0EB1E102K T
C59 4030017350 S.CERAMIC ECJ0EC1H020B T
C60 4030016790 S.CERAMIC ECJ0EB1C103K B
C61 4030017460 S.CERAMIC ECJ0EB1E102K B
C62 4550006200 S.TANTALUM ECST0JY106R B
C63 4030017700 S.CERAMIC ECJ0EC1H151J B
C64 4030017640 S.CERAMIC ECJ0EC1H150J B
C65 4030016790 S.CERAMIC ECJ0EB1C103K B
C66 4030016790 S.CERAMIC ECJ0EB1C103K B
C69 4030017460 S.CERAMIC ECJ0EB1E102K B
C70 4030017460 S.CERAMIC ECJ0EB1E102K T
C71 4030017360 S.CERAMIC ECJ0EC1H030B T
C73 4030017460 S.CERAMIC ECJ0EB1E102K T
C74 4030017460 S.CERAMIC ECJ0EB1E102K B
C75 4030017460 S.CERAMIC ECJ0EB1E102K T
C92 4030016790 S.CERAMIC ECJ0EB1C103K T
C93 4030017460 S.CERAMIC ECJ0EB1E102K T
C94 4030017460 S.CERAMIC ECJ0EB1E102K T
C95 4030017460 S.CERAMIC ECJ0EB1E102K T
C96 4030016790 S.CERAMIC ECJ0EB1C103K T
C97 4030016790 S.CERAMIC ECJ0EB1C103K T
C98 4030017730 S.CERAMIC ECJ0EB1E471K T
C99 4030017730 S.CERAMIC ECJ0EB1E471K T
C100 4030016930 S.CERAMIC ECJ0EB1A104K T
C101 4030017620 S.CERAMIC ECJ0EC1H100C T
C102 4030017460 S.CERAMIC ECJ0EB1E102K T
C103 4030016790 S.CERAMIC ECJ0EB1C103K T
C121 4030017460 S.CERAMIC ECJ0EB1E102K B
C134 4030017460 S.CERAMIC ECJ0EB1E102K T
C136 4030017590 S.CERAMIC ECJ0EC1H070C T
C138 4030017730 S.CERAMIC ECJ0EB1E471K T
C141 4030016790 S.CERAMIC ECJ0EB1C103K T
C142 4030017460 S.CERAMIC ECJ0EB1E102K T
C145 4030017460 S.CERAMIC ECJ0EB1E102K T
C147 4030017560 S.CERAMIC ECJ0EC1H2R5B T
C148 4030017730 S.CERAMIC ECJ0EB1E471K T
C150 4030017460 S.CERAMIC ECJ0EB1E102K T
C153 4030016930 S.CERAMIC ECJ0EB1A104K T
C200 4030016790 S.CERAMIC ECJ0EB1C103K B
C201 4030016930 S.CERAMIC ECJ0EB1A104K T
C202 4030016930 S.CERAMIC ECJ0EB1A104K T
C203 4030016930 S.CERAMIC ECJ0EB1A104K B
C206 4030017370 S.CERAMIC ECJ0EC1H3R5B T
C214 4030017460 S.CERAMIC ECJ0EB1E102K T
C218 4030017340 S.CERAMIC ECJ0EC1H010B T
C221 4030016790 S.CERAMIC ECJ0EB1C103K T
C233 4030017460 S.CERAMIC ECJ0EB1E102K B
S.=Surface mount
C239 4030016790 S.CERAMIC ECJ0EB1C103K T
C241 4030011810 S.CERAMIC C1608 JB 1A 224K-T B
C242 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C259 4030017430 S.CERAMIC ECJ0EC1H101J T
C264 4030017460 S.CERAMIC ECJ0EB1E102K T
C402 4030017460 S.CERAMIC ECJ0EB1E102K B
C408 4030017460 S.CERAMIC ECJ0EB1E102K B
C410 4030017460 S.CERAMIC ECJ0EB1E102K T
C414 4030017460 S.CERAMIC ECJ0EB1E102K T
C416 4030017650 S.CERAMIC ECJ0EC1H270J B
C424 4030016790 S.CERAMIC ECJ0EB1C103K T
C427 4030017400 S.CERAMIC ECJ0EC1H220J T
C430 4030016790 S.CERAMIC ECJ0EB1C103K T
C431 4030016790 S.CERAMIC ECJ0EB1C103K T
C432 4030017460 S.CERAMIC ECJ0EB1E102K T
C433 4030017460 S.CERAMIC ECJ0EB1E102K B
C434 4030016930 S.CERAMIC ECJ0EB1A104K B
C435 4030017460 S.CERAMIC ECJ0EB1E102K T
C436 4030017360 S.CERAMIC ECJ0EC1H030B T
C503 4030017460 S.CERAMIC ECJ0EB1E102K B
C504 4030017460 S.CERAMIC ECJ0EB1E102K B
C505 4030017460 S.CERAMIC ECJ0EB1E102K B
C511 4030018010 S.CERAMIC ECJ0EC1H360J B
C512 4030017620 S.CERAMIC ECJ0EC1H100C B
C513 4030017430 S.CERAMIC ECJ0EC1H101J B
C514 4030017710 S.CERAMIC ECJ0EC1H181J B
C515 4030017690 S.CERAMIC ECJ0EC1H121J B
C516 4030017440 S.CERAMIC ECJ0EC1H221J B
C517 4030017430 S.CERAMIC ECJ0EC1H101J B
C518 4030017440 S.CERAMIC ECJ0EC1H221J B
C519 4030017780 S.CERAMIC ECJ0EB1E472K B
C520 4030018080 S.CERAMIC ECJ0EB1H182K B
C521 4030016930 S.CERAMIC ECJ0EB1A104K B
C522 4030017910 S.CERAMIC ECJ0EB1H152K B
C523 4030017910 S.CERAMIC ECJ0EB1H152K B
C524 4030016790 S.CERAMIC ECJ0EB1C103K B
C525 4030017780 S.CERAMIC ECJ0EB1E472K B
C526 4030017900 S.CERAMIC ECJ0EB1C123K B
C527 4030017420 S.CERAMIC ECJ0EC1H470J B
C528 4030017620 S.CERAMIC ECJ0EC1H100C B
C529 4030017700 S.CERAMIC ECJ0EC1H151J B
C530 4030017450 S.CERAMIC ECJ0EB1E271K B
C531 4030017430 S.CERAMIC ECJ0EC1H101J B
C532 4030016930 S.CERAMIC ECJ0EB1A104K B
C533 4030017910 S.CERAMIC ECJ0EB1H152K B
C534 4030017430 S.CERAMIC ECJ0EC1H101J B
C535 4030017750 S.CERAMIC ECJ0EB1E122K B
C536 4030016930 S.CERAMIC ECJ0EB1A104K B
C537 4030016930 S.CERAMIC ECJ0EB1A104K B
C538 4030016930 S.CERAMIC ECJ0EB1A104K B
C539 4030016930 S.CERAMIC ECJ0EB1A104K B
C540 4030016930 S.CERAMIC ECJ0EB1A104K B
C541 4030016930 S.CERAMIC ECJ0EB1A104K B
C542 4030016930 S.CERAMIC ECJ0EB1A104K B
C543 4030017460 S.CERAMIC ECJ0EB1E102K B
C544 4030017460 S.CERAMIC ECJ0EB1E102K B
C545 4030016790 S.CERAMIC ECJ0EB1C103K B
C546 4030016930 S.CERAMIC ECJ0EB1A104K B
C548 4030017460 S.CERAMIC ECJ0EB1E102K B
C558 4030017460 S.CERAMIC ECJ0EB1E102K B
C560 4030017460 S.CERAMIC ECJ0EB1E102K T
C561 4030017460 S.CERAMIC ECJ0EB1E102K B
C562 4030017460 S.CERAMIC ECJ0EB1E102K B
C563 4030017460 S.CERAMIC ECJ0EB1E102K B
C566 4030016790 S.CERAMIC ECJ0EB1C103K B
C567 4030016930 S.CERAMIC ECJ0EB1A104K B
C568 4030017420 S.CERAMIC ECJ0EC1H470J T
C569 4030016930 S.CERAMIC ECJ0EB1A104K B
C570 4030017460 S.CERAMIC ECJ0EB1E102K B
C571 4030017460 S.CERAMIC ECJ0EB1E102K B
C657 4030017700 S.CERAMIC ECJ0EC1H151J B
C658 4030018140 S.CERAMIC ECJ0EB1H391K B
C659 4550006200 S.TANTALUM ECST0JY106R B
C662 4030016930 S.CERAMIC ECJ0EB1A104K T
C663 4030016930 S.CERAMIC ECJ0EB1A104K T
C664 4030016930 S.CERAMIC ECJ0EB1A104K T
C665 4030017430 S.CERAMIC ECJ0EC1H101J T
C666 4030018140 S.CERAMIC ECJ0EB1H391K T
C667 4030016790 S.CERAMIC ECJ0EB1C103K B
C669 4030017460 S.CERAMIC ECJ0EB1E102K B
C673 4030017460 S.CERAMIC ECJ0EB1E102K T
6 - 12
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
