Icom IC-R20 Service Manual

9 - 5
The combination of this page and the next page shows
the unit layout in the same configuration as the actual
P. C. Board.
GND
AOUT
B_AIN
A_ATN
4
1
to LOGIC UNIT HJ8
J6
VL DOWN
USB
VL UP
SQL
+3V
SUB_3C
VOL_UP_DOWN
SQL
CPU_TX
CPU_RX
1
6
to LOGIC UNIT HJ9
J7
9-3 REC UNIT
• TOP VIEW

Icom IC-R20 Specifications

General

Mode	AM, FM, WFM, SSB, CW
Antenna Connector	BNC
Memory Channels	1250
Selectivity	AM/FM
Output Power	150mW at 8 Ohms
Battery Life	Approx. 8 hours with BP-206 (at 50mW audio output)
