ANI FUNCTION
D Calling group stations
q Select the desired ANI set channel.
w When using HM-118TN/TAN:
Push [
MM
] then enter the 3-digit group code. [A] or [D] must
be included at least once.
When using HM-133V:
Push [
MM
(TONE-1)] then enter the 3-digit group code.
[
CLR A(MW)] or [ SQL Y D(MUTE)] must be included at least
once.
• Transmits automatically after the 3rd digit code is entered.
• When making group calls, the transceiver does not ring and no
answer back connection code is received.
• You can make an announcement to your group immediately
without a connection procedure.
•“ ” blinks.
e Operate the transceiver in the normal way (push [PTT] to
transmit; release [PTT] to receive).
r When your conversation is finished, push [#] while pushing
[PTT] (HM-118TN/TAN), or push [DTMF-S] then [ SQL Z #(16KEY-
L)]
(HM-133V) to transmit a disconnect code.
D Group code examples
[Example 1]: If the “11D (11A)” is transmitted, the trans-
ceivers with ID codes “110” to “119” are called.
[Example 2]: If the “1D3 (1A3)” is transmitted, the trans-
ceivers with ID codes “103,” “113,”...“183” and
“193” are called.
NOTE: When “DDD (AAA)” code is transmitted, all trans-
ceivers are called.
D Waiting for a call
q Select the desired ANI set channel, or push
[V//MHz(SCAN)] for 1 sec.
w When receiving a selective call, the display changes as
below, and ringing beeps are heard.
e Push [PTT] to send a connection code within 10 sec.
• A disconnect code is sent automatically instead of a connection
code in case [PTT] operation is not performed within 10 sec.
r While “” blinks, converse with the connected station.
• Transmitting the disconnect code from your side (push [#] while
pushing [PTT] or push [DTMF-S] then push [ SQL Z #(16KEY-L)])
is also available. (except for group call receive)
•“ ” stops blinking.
When called from the station
“123.”
During ANI conversation.
