5
OPTIONAL PRODUCTS
5-16
■ Connecting and disconnecting (continued)
Connecting with the VS-3 when the Bluetooth indicator is OFF
1. Turn ON the IP501H's Bluetooth function. (p. 5-12)
2. Hold down the [PWR] button on the VS-3 for 3 seconds.
• The Bluetooth function is ON, and the Bluetooth indicator Blinks blue.
• After few seconds, a beep sounds and the Bluetooth connection between the IP501H and the VS-3 is established.
Connecting with the VS-3 when the Bluetooth indicator blinks blue
1. Turn ON the IP501H's Bluetooth function. (p. 5-12)
2. Hold down [PTT] on the VS-3 for 3 seconds.
• After few seconds, a beep sounds and the Bluetooth connection between the IP501H and the VS-3 is established.
L The paired device can be identied by its BD address on the “Pairing List.” (p. 5-17)
Earphone (3.5 (d) mm)
Example
L
R
Earphone (3.5 (d) mm)
Example
L
R
LED
LED
[PWR]
[PTT]
