9
Side Panel Layout
1. USB port
Functions as a MIDI port to your notebook (or computer) and compatible
software.
2. Platform D / Platform D2 connector
Connect your Platform D / Platform D2 to this connector with the provdied cable.
3. 12V/2.5A power adaptor
Connect the provided power adaptor here.
(Note: Platform X+ is not able to work without the provided power adaptor
connected. The USB bus power is not able to provide sufcient power supply for
Platform X+.)
Note: Due to the software issue. The functions listed below will not work
proeprly on ProTools if Platform X+ is used as a extender unit of Platform M+.
1 23
