ICON FREEMOTION 530 INTERACTIVE - Page 13

13
10. Attach the console assembly (E) with two 5/16"
x 1 1/4" Screws (5), two 5/16" x 1 3/4" Screws
(9), and four 5/16" Washers (11); start all four
Screws, and then tighten them.
10
9
E
11
11. Attach the Right and Left Handrail Covers (31,
87) with six #8 x 3/4" Screws (4); do not over-
tighten the Screws.
11
87
31
4
11
11
5
4
9
5
