Step 3: Configuring the Pair-connection (Client Mode) on the Web Server
for tGW-700#1
1. Open the eSearch Utility to search for the tGW-700/GW-2200 modules connected to the
network. Click the name of the first tGW-700 module (tGW-700#1) to select it, and then click
the “Web” button to launch a browser window to connect to the web server on the tGW-700 #1
module. Alternatively, you can enter the URL for tGW-700 #1 in the address bar of the browser.
2. When the login screen is displayed, enter the password (use the default password “admin”) in
the Password field, and then click the “Submit” button to display the configuration page.
3. Click the “Port1” tab to display to the Port1 Settings page.
