633GC SHOP MANUAL
8.14 Wind the recoil spring.
A Line rope up with notch on pulley.
B Rotate the pulley with the rope
clockwise 5 times.
C Untangle rope and release.
8.15 Assemble starter cord shield.
8.16 Remove starter pawl snap rings,
pawls, spring, and plain washer.
8.17 Inspect and clean pawl components.
A Inspect the components. Replace if
necessary.
B Clean the components with a brush
and solvent.
8. STARTER
