58
Interface Used Voltage Harness
MDB 10 – 45V DC WEL-RCC72 (MDB)
Interface Peripheral Harness
MDB MDB Peripheral WEL-RCC72 (MDB Peripheral)
Warning!! Do not plug both MDB and Executive connector to VMC board
simultaneously!! It may cause damage of VMC board.
