7.2. Error Handling
« LCM Panel Open »
Code: E10
LED Light Display: 5 red+ 2 red
LCM Display: As shown in figure
Cause: LCM Panel Open
Corrective Measure: Close the
LCM panel and verify that the
latch is in place. If the problem
cannot be solved, notify ICT
personnel for support.
« Checksum Error »
Code: E11
LED Light Display: Red light
LCM Display: As shown in figure below
Cause: Check Sum Error.
Corrective Measure: Notify the ICT personnel for support.
Sorting Module
Door Open E10
Check Sum Error
E11
