4.5. Wire Harness Pin Assignment for Executive & MDB Interface
Interface Used Voltage Harness
Executive 24V AC WEL-RCC54
Interface Peripheral Harness
Executive MDB Peripheral WEL-RCC72 (MDB Peripheral)
WEL-RCC54
