11.3. Coin Discharge Module Disassembling:
1. Remove the two screws on the sides of the
coin discharge module.
2. Rotate the coin discharge module downward
90 degrees.
3. Unplug the wire connecting to the coin
discharge module.
4. Pull and remove the coin discharge module.
