Payout Mode Error

Code: E12

LED Light Indicator: Red light

LCM Display: As shown in figure below

Cause: Signal from payout module was not

received when power was turned on.

Corrective Method: Ensure that the signal wire

is connected to the payout module.

Communication Error

Code: E13

LED Light Display: 1 red

LCM Display: As shown in figure

Cause:

1. Two seconds after activation, the SYSTEM did not wait for the READY signal from

the DEVICE and jumped to the exception mode.

2. Two seconds after a transaction, the SYSTEM did not wait for the READY signal

triggered by the DEVICE.

Corrective Measure:

1. Ensure that the machine interface and the VMC

interface are consistent.

2. Ensure that the interface transmission wire is

properly connected.

Payout Module Error

E12

No Communication

with VMC E13
