Reader Connection
The recommended cable types for RS-485 are:
⦁ Belden 9842 or equivalent
⦁ 24 AWG twisted pair with characteristic impedance of 120ohm
The recommended cable types for Wiegand are:
⦁ 22 AWG alpha 5196, 5198, 18 AWG alpha 5386, 5388
Warning: The reader outputs D0 (green wire) and D1 (white wire) can switch to a maximum capacity of
50mA. Exceeding this amount will damage the output.
PRX-TSEC Range | tSec Multi-Technology Card Reader with Bluetooth® Technology | Installation Manual 13
