ICT PRX-TSEC User Manual

Technical Specifications
The following specifications are important and vital to the correct operation of this product. Failure to adhere to
the specifications will result in any warranty or guarantee that was provided becoming null and void.
Ordering Information
Order Codes See tSec Reader editions.
Power Supply
Operating Voltage 12VDC (9.5 to 14VDC)
Operating Current
tSec Standard Reader: 254mA (peak, reading)
tSec Extra Reader: 298mA (peak, reading)
tSec Mini Reader: 203mA (peak, reading)
Communications
Card Read Range
MIFARE 60mm (2.36") *
DESFire EV1 ISO 15mm (0.6") *
125kHz Clamshell 40mm (1.57”) †
Tag Read Range
MIFARE 30mm (1.2") *
DESFire EV1 6mm (0.23") *
125kHz 25mm (0.98”) †
Wiegand Interface Multiple format 26 or 34 Bit data 0 and data 1, card defined.
Frequency
13.56 MHz ISO/IEC 14443 Type A *
125KHz pulse width modulated †
Multi Conductor Cable
Wiegand: 22Awg alpha 5196, 5198, 18Awg alpha 5386, 5388. Max Distance 150m
(492ft)
Module comms/RS485: Belden 9842 or equivalent. Max distance 900m
(3000ft)
OSDPCommunication OSDP standard 2.1.5 with Secure Channel Protocol ** / ***
Bluetooth® Wireless Technology
Bluetooth® Read Range
Proximity mode: up to 0.5m (1.6ft) Configurable **
Action unlock (shake): up to 5m (16.4ft) Configurable **
Bluetooth® Electronic
Credential Transmission
Technology
NRF8001 Bluetooth® version 4.0 compliant
Proprietary data exchange protocol. AES128 Encrypted
Reader App Version: 1.04.175 and above
Credentials can be distinguished by unique site code and card number
Bluetooth® Wireless Device Protege Mobile 1.0.x
NFC
NFC Read Range Up to 60mm ***
NFC (Near-field
communication) electronic
credential transmission
technology
Android 4.4 or above, with phones which support ISO7816-4
Proprietary Secured DESFire credential
Credential is AES-256 (NIST certified AES algorithm)
Reader App Version: 1.04.175 and above
Credentials can be distinguished by unique site code and card number
PRX-TSEC Range | tSec Multi-Technology Card Reader with Bluetooth® Technology | Installation Manual 30
