iData 70 User Manual
- 27 -
Supported language
Java, C
Management tool
iData Tools
Operating temperature
-10C to 50C
Operating Environment
Storage temperature
-20C to 60C
Relative humidity
0 to 95% (non-condensing)
Drop specification
1.5-meter drop on concrete ground
Tumble specification
500 0.5-meter tumbles (1000 hits)
Sealing standard
IP65
Electrostatic discharge
15 kV air discharge,  8 kV direct discharge
Structural Parameters
Dimensions (LxWxD)
152 mm x 68 mm x 24 mm
Weight
255 g (standard battery included)
Communication & Transmission
Wireless voice
communication
2G: GSM 850/900/1800/1900 MHz
3G: TD-SCDMA 1880–1920MHz/2010–2025MHz
WWAN
GPRS/EDGE/TD-SCDMA
WLAN
Wi-Fi 802.11b/g/n
GPS
High-performance GPS chip
Input/Input Interface
USB port
1 (Micro USB port)
Charger port
1 (DC port)
RS232 port
1
Data Collection Specification
1D Laser Scanner
Optical resolution
 4 mil
Scan depth
3.81 cm - 60.98 cm
Scan angle
47° 3° (Standard)
Scan speed
102  12 scans/sec. (Bidirectional)
1D linear imager
Reading mode
CCD
Reading accuracy
 4 mil
Decoding speed
300 times/sec. (Max.)
2D area imager
Optical resolution
 3 mil
Scan angle
Omnidirectional
Scan speed
300 scans/sec.
Infrared Communication Module
Built-in infrared
communication module
Structure with two emitting tubes, meter reading distance of up to 5
meters, fully supporting DL/T645 protocol and communication
protocols of worldwide mainstream meter manufacturers
Interface
Initial rate: 1200 bps, supported rates: 1200, 2400, 4800, and 9600
bps
