Ideal Heating LOGIC MAX SYSTEM2 S24 - Flue System Dimensions; Fitting the Turret

20
Installation and Servicing
Section 2 - Installation
INSTALLATION
2.11 FLUE SYSTEM DIMENSIONS 2.12 FITTING THE TURRET
Flue Design
IMPORTANT:
1. Flue lengths may vary, always measure ue lengths
before cutting.
2. E󰀨ective ue length and actual ue length are di󰀨erent
measurements.
3. E󰀨ective ue length is made up of the ue length
equivalence and the ue sections between the turret,
elbows and terminal.
4. Actual ue length is the amount of ue needed to achieve
the e󰀨ective ue length, this includes insertions.
Retaining
screw
Clamp Lugs
Sample points
Flue Outlet
C
A
A - Duct Assembly
B - Flue Turret
C - Turret Clamp
D - Seal
Flue Outlet
D
B
1. Ensure the condensate trap in lled with water
2. Ensure the rubber seal is not damaged and tted
correctly on the appliance manifold.
3. Firmly hold the ue and push the turret on until it has
travelled 30 mm ensuring the ue has not rotated or
moved forward.
4. Push the turret into the manifold ensuring the upper
plastic lip is ush with the top of the manifold.
5. Fully engage the clamp location section into the manifold
location hole and rotate down onto the ange.
6. Use the securing screws to secure the clamp to the
appliance.
7. Ensure all sample points are accessible and all sample
plugs and caps are tted.
30
30
Elbow insertion (mm)Turret insertion (mm)
100mm
Edge of turret
to outside face of wall plus
44mm = ue length
A
WALL
Part Actual
Length
Insertion E󰀨ective
Length
1 m ue length 1000 mm 30 mm 970 mm
90° elbow n/a 1000 mm
1 m ue length 1000 mm 30 mm 970 mm
90° elbow n/a 1000 mm
0.6 m ue terminal 600 mm 30 mm 570 mm
Total 4.510 mm
