FLUE OUTLET
SECTION 2 - INSTALLATION
Note.
A at or pitched roof ashing plate (not supplied) is required before proceeding
with the installation of this kit.
This kit is suitable for both at and pitched roof terminations, using a concentric
ue to run vertically from the top of the boiler and terminating above roof level.
Connection to the top of the boiler is made using a separately supplied vertical
connector.
WEATHER PROOFING
Where the ue passes through the roof line an adequate seal must be made.
This is achieved by using either:
- Flat roof weather collar
or
- Universal weather collar.
ACCESSORIES
Flue Duct Extension Kits are available for ue lengths extending beyond 1m.
These packs contain 500mm, 1000mm or 2000mm extension ducts and may
be cut to the desired length.
If the offset vertical option is used an Elbow Kit is required.
Please visit idealheating.com to access the Flue and Accessories Guide for this
boiler.
2.12 FITTING THE OPTIONAL ROOF FLUE KIT (Flat or Pitched)
