2.3 UNPACKING - INTERNAL BOILER
2.4 UNPACKING - EXTERNAL BOILER
Unpack and check the contents.
C
A
D
F
E
B
Pack Contents
A Boiler
B Accessory Pack
C Compression Coupler
D Wall Mounting Plate
E Installation / User Instructions
F Wall Mounting Template (located on
internal protective packaging)
A
B
C
D
E
Unpack and check the contents.
Pack Contents
A Boiler
B Hardware Pack
(includes ue,
installation instructions,
PRV Compression Coupler
& other xings)
C Wall Mounting Template
D Weather Shield
E Wall Mounting Bracket
