6
Installation and Servicing
SECTION 1 - GENERAL
Natural Gas only
Destination Country: AU, NZ
LOGIC+ SYSTEM S
Boiler Page
Make and model ......................................................... 6
Appliance serial no. on data badge .......... Front Cover
SEDBUK No. % .......................................................... 5
Controls
Time and temperature control to heating ................. 29
Time and temperature control to hot water ........... N/A
Heating zone valves ................................................. 29
TRV’s........................................................................ 10
Auto bypass ............................................................. 10
Boiler interlock .......................................................... 10
For .................................................................... all boilers
Flushing ................................................................... 14
Inhibitor .................................................................... 14
Central heating mode
Heat input ...................................................to be calculated
For assistance see Technical Helpline on the back Page
Page
Burner operating pressure ...................................... n/a
Central heating ow temp. ...........measure and record
Central heating return temp. ........measure and record
For combination boilers only
Scale reducer ........................................................... 14
Hot water mode
Heat input ............................................ to be calculated
Max. operating burner pressure .............................. n/a
Max. operating water pressure ........ measure & record
Cold water inlet temp ...................... measure & record
Hot water outlet temp. ..................... measure & record
Water ow rate at max. setting ........ measure & record
For condensing boilers only
Condensate drain ..................................................... 27
For all boilers: complete, sign & hand over to customer
COMMISSIONING CHECKLIST DETAILS
NOTE TO THE INSTALLER: COMPLETE THE COMMISSIONING CHECKLIST AND LEAVE THESE
INSTRUCTIONS WITH APPLIANCE
