Ideal-Standard Easybox Slim A5959AA - Page 24

Slide bar kit with
handspray and hose
Cold water
Hot water
Mixed water
As illustraded, top
outlet used & bottom
outlet blanked off.
Alternative, bottom
outlet used & top
outlet blanked off.
Basic installation example showing thermostatic shower valve with integrated
“flow control” connected to a single outlet slide bar shower kit.
40
Wall outlet elbow to hose
24
