This installation instruction covers two main products types (both dual control):
• Products with integral on/off ow control: A5877AA, A5878AA, A5958AA, & A5959AA.
The temperature and the ow rate of the water can be adjusted using the two control handles
on the valve. The outlet device is normally a shower.
• Products with integral 3 function diverter: A5879AA & A5880AA.
The temperature of the water can be adjusted with the lower control handle on the valve.
The upper handle is used to diverter the mixed water to either a shower device, a bath ll
device or to switch off the water ow.
4.0 Pre-installation notes:
4.1 Overview of kits 1 & 2
For built-in products the installation is normally carried out in two stages:
During rst-x (kit-1) the valve-box is installed into the wall or panel.
During second-x (kit-2) the chromed trim is tted, usually after nishing (tiling) the wall.
4.2 Kit-1 mounting depth control
IMPORTANT: For trouble-free installation of these built-in products the depth controls shown
must be observed. Using a spirit level ensure valve-box is level in all 3 directions.
The valve-box is marked with MIN & MAX depth settings, the nished wall (after tiling) should lie
between these markers as shown
MAX
MIN
MAX
MIN
Finished wall or panel
Lines on valve.box
serve as trimming guide
for installing kit-2
When calculating depth, consider
thickness of plaster, tile adhesive,
& tiles (if applicable).
8
