IDEAL EVOMAX 2 Series User Manual

2
CONTENTS
1. Introduction ................................................... 3
Safety .............................................................. 3
Electricity Supply ............................................. 3
Important Notes ............................................... 4
Minimum Clearances ....................................... 4
2. Boiler Operation ............................................ 5
Controls Diagram............................................. 5
To light the boiler ............................................. 6
Operating Status.............................................. 7
Settings............................................................ 8
3. Installer Connections .................................. 20
4. Faults ............................................................ 21
Faults - Hardware (Thermistors, Actuators)... 22
Faults - Temperature Supervisions ................ 23
Faults -
System (Flame, Fan, Hydraulic, etc.) . 24
Faults - Internal System................................. 25
5. General Information .................................... 26
To shut down the boiler .................................. 26
To relight the boiler ........................................ 26
Frost Protection ............................................. 26
Boiler Overheat Thermostat .......................... 29
Condensate Drain.......................................... 26
Escape of Gas ............................................... 27
Cleaning ........................................................ 27
6. System Set up information ......................... 28

IDEAL EVOMAX 2 Series Specifications

General

Model	EVOMAX 2 Series
Category	Boiler
Fuel Type	Natural Gas
Boiler Type	Condensing
Installation	Wall-mounted
Heating Capacity	40kW, 60kW, 80kW, 100kW, 120kW, 150kW
