OPERATING STATUS
The status screens are dependent upon the boiler conguration, they are shown below:
IDEAL Evomax 2 150kW
Operation: Htg. with capacity
Capacity Set point: 40%
Capacity: 0%
Flow temp: 40.2ºC
IDEAL Evomax 2
Operation: Htg. with temp.
Voltage: 5.6V
Flow Set point: 40.2ºC
Flow temp: 40.2ºC
IDEAL Evomax 2 150kW
Operation: Htg. with capacity
Voltage: 5.6V
Capacity Set point: 40%
Capacity: 0%
IDEAL Evomax 2 150kW
Status: OpenTherm
Operation: Day
Room set point: 20.0ºC
Flow set point: 60.0ºC
IDEAL Evomax 2 150kW
Status:
Operation: Night
Tank temperature: 45.0ºC
Flow set point: 30.0ºC
IDEAL Evomax 2 150kW
Operation: Htg. with temp.
Flow Set point: 40.2ºC
Flow temp: 40.2ºC
Master non cascade
Master / Non-cascade Slave
Menu item: Heating circuit / Status / Summary /
HC1 Boiler 1.1
Menu item: DHW / Status / Summary / HC1
Boiler 1.1
Master non cascade,
0-10V control
The heating circuits and DHW circuits also have status screens associated with them. e.g.
