IDEAL icos HE12 User Manual

15
icos - Installation & Servicing
INSTALLATION
The boiler is supplied fully assembled in one Pack A,
together with a telescopic flue assembly for lengths up to
595mm, rear or side flue outlet, in Pack B.
Unpack and check the contents.
11 UNPACKING
Hardware Pack
A 50mm x No.14 wood screws - 3 off
B Wall plugs (TP2B ) - 3 off
C Push-in caps - 6 off (Refer to Frame 36 no. 15)
D Mains connector - 1 off
Pack A Contents
A The boiler
B Wall mounting template
on cardboard
C Wall mounting plate
D 1 year guarantee form
E These Installation & Servicing/
User’s Instructions
F Hardware pack
B Pack Contents
A Telescopic flue terminal
B Flue turret
C Rubber Terminal Wall Seal
D Screw
E Sealing Tape
C
nm8465
D
A
B
isfu8751d
D
C
B
A
E
C
A
B
E
F
D
nm9315
INSTALLATION

IDEAL icos HE12 Specifications

General

Model	icos HE12
Category	Boiler
Manufacturer	IDEAL
Output	12 kW
Fuel Type	Natural Gas
Mounting	Wall Mounted
ErP Heating Efficiency	A
Central Heating Flow Temperature Range	30-80°C
Dimensions	700 x 395 x 278 mm
Warranty	2 years
