Note.
A at or pitched roof ashing plate (not supplied) is required before proceeding
with the installation of this kit.
This kit is suitable for both at and pitched
roof terminations, using a concentric ue to
run vertically from the top of the boiler and
terminating above roof level.
Connection to the top of the boiler is made
using the supplied vertical connector.
WEATHER PROOFING
Where the ue passes through the roof line
an adequate seal must be made. This is
achieved by using either:
- Flat roof weather collar
or
- Universal weather collar.
ACCESSORIES
Flue Duct Extension Kits are available for ue
lengths extending beyond 1m. These packs
contain 1m extension ducts and may be cut
to the desired length.
If the offset vertical option is used an elbow
Kit is required. For a full accessories list refer
to page 9, Optional Extras.
