IDEAL Logic+ SYSTEM 30 User Manual

7
Ideal Logic + System - Installation and Servicing
general
Boiler size G.C. Appliance No. PI No.

15 41-750-29 86 CL 08
18 41-750-30 86 CL 08
24 41-750-31 86 CL 08
30 41-750-32 86 CL 08
CONTENTS
Air Supply .....................................................................11
 ..................... 58
Boiler Clearances ....................................................... 12
 ........................................... 15
 .................................................. 26,27
Commissioning & Testing ......................................... 32
Electrical Connections ............................................... 29
Electrical Supply ..........................................................11
 ..........................................................50-54
Flue Fitting .................................................................. 19
Flue Installation .......................................................... 10
Gas Safety Regulations ............................................... 9
Gas Supply .................................................................. 10
I ............................................................ 33
Installation .............................................................15-34
Pump ........................................................................... 47
 ................................................................ 8
 ................................................................35-49
Spare Parts Info .......................................................... 55
 ....................................11
 ......................................... 11,13-14
Water Connections ................................................ 12,28
Water Treatment ........................................................ 14
Wiring Diagram ........................................................... 31
Natural Gas only
Destination Country: GB, IE
Boiler Page
Make and model .........................................................7
Appliance serial no. on data badge ..........Front Cover
SEDBUK No. % ..........................................................6
Controls
Time and temperature control to heating .................29
Time and temperature control to hot water ........... N/A
Heating zone valves .................................................29
TRV’s........................................................................ 11
Auto bypass ............................................................. 11
Boiler interlock .......................................................... 11
For .................................................................... all boilers
Flushing to BS.7593 .................................................14
Inhibitor ....................................................................14
Central heating mode
Heat input ...................................................to be calculated
For assistance see Technical Helpline on the back page
Page
Burner operating pressure ......................................n/a
Central heating ow temp. ...........measure and record
Central heating return temp. ........measure and record
For combination boilers only
Scale reducer ........................................................... 14
Hot water mode
Heat input ............................................ to be calculated
Max. operating burner pressure .............................. n/a
Max. operating water pressure ........ measure & record
Cold water inlet temp ...................... measure & record
Hot water outlet temp. ..................... measure & record
Water ow rate at max. setting ........ measure & record

Condensate drain ................................................26,27
For all boilers: complete, sign & hand over to customer
For GB, to comply with Building Regulations Part L1 (Part 6 in Scotland) the boiler should be tted in accordance with the
manufacturer’s instructions. Self-certication that the boiler has been installed to comply with Building Regulations can be
demonstrated by completing and signing the Benchmark Commissioning Checklist.
Before installing this boiler, read the Code of Practice sheet at the rear of this book.
BENCHMARK COMMISSIONING CHECKLIST DETAILS
NOTE TO THE INSTALLER: COMPLETE
THE BENCHMARK COMMISSIONING

INSTRUCTIONS WITH APPLIANCE
IDEAL LOGIC + SYSTEM

IDEAL Logic+ SYSTEM 30 Specifications

General

Boiler Type	System
Model	Logic+ SYSTEM 30
Output	30 kW
Dimensions (H x W x D)	700 x 395 x 278 mm
Fuel Type	Natural Gas
Warranty	7 years
ERP Rating	A
Mounting	Wall-mounted
Max Working Pressure	3 bar
Central Heating Flow Temperature Range	30-80°C
Efficiency Rating	ErP A-rated
