18
Battery Indicator: [][][][]
User Name: User’s name (Name can be changed
in the Main menu)
Model & Software versions are subject to change without
notice.
Mode Setup
Pressing the key changes the operation mode
between VIDEO, DMM, PTZ, and UTP.
To directly select a mode, press and hold the
key for 3 seconds then choose a mode and press the
key again to select the mode.
Video Tester Mode:
In this mode, the image quality of the external input
picture signal is tested. Unlike most monitors,
SecuriTEST does not have a video input amplifier,
thus picture quality problems caused by long cable
runs or poor connectors will be seen. The same signal
input into a standard external monitor may look fine
since the monitor will boost the signal to make the
image look clear. The un-amplified input circuit allows
users to troubleshoot cable and connector problems
that would normally go unnoticed. The VIDEO mode
also outputs color test patterns to aide in
troubleshooting or setting up monitors.
