4
vogue combination boiler -
Installation and Servicing
gENERAL
Vogue 26 32 40
Gas supply 2H - G20 - 20mbar
Gas Supply Connection 22mm copper compression
Injector Size (mm) 4.30 4.40 5.15
Inlet Connection Domestic Hot Water 15mm copper compression
Outlet Connection Domestic Hot Water 15mm copper compression
Flow Connection Central Heating 22mm copper compression
Return Connection Central Heating 22mm copper compression
Flue Terminal Diameter mm (in) 100 (4)
Average Flue Temp-Mass Flow Rate (DHW) ºC (g/s) 73ºC (11 g/s) 73ºC (13 g/s) 70ºC (17 g/s)
Maximum Working Pressure (Sealed Systems) bar (lb/in
2
) 2.5 (36.3)
Maximum Domestic Hot Water Inlet Pressure bar (lb/in
2
) 10.0 (145)
Minimum Domestic Hot Water Inlet Pressure* bar (lb/in
2
) 1.1 (16.0) 1.5 (21.8) 1.5 (21.8)
Electrical Supply 230 V ~ 50 Hz.
Power Consumption W 108 137 133
Fuse Rating External : 3A Internal : 4A Time Delay
Water content Central Heating litre (gal) 1.5 (0.33) 1.8 (0.41) 2.2 (0.48)
Domestic Hot Water litre (gal) 0.5 (0.11)
Packaged Weight kg (lb) 40.4 (89) 41.7 (92) 43.7 (96)
Maximum Installation Weight kg (lb) 35.0 (77) 36.4 (80) 38.0 (84)
Boiler Casing Size Height mm (in) 740 (29.1)
Width mm (in) 445 (17.5)
Depth mm (in) 330 (13)
Heat Exchanger Weight without Burner KG 7.3 8.2 9.5
Table 1 - general Data
Note. Gas consumption is calculated using a
caloric value of 38.7 MJ/m
3
(1038 Btu/ft
3
) gross
or 34.9 MJ/m
3
(935 Btu/ft
3
) nett
To obtain the gas consumption at a different
caloric value:
a. For l/s - divide the gross heat input (kW) by
the gross C.V. of the gas (MJ/m
3
)
b. For ft
3
/h - divide the gross heat input (Btu/h)
by the gross C.V. of the gas (Btu/ft
3
)
c. For m
3
/h - multiply l/s by 3.6
Key to symbols
gB = United Kingdom IE = Ireland (Countries of destination)
pMs = Maximum operating pressure of water
C
13
C
33
C
53
* = A room sealed appliance designed for connection via ducts to a
horizontal or vertical terminal, which admits fresh air to the burner
and discharges the products of combustion to the outside through
orices which, in this case, are concentric. The fan is up stream
of the combustion chamber. (*Note. C
53
covers optional high level
and balconly ue kits only.)
I
2h
= An appliance designed for use on 2nd Family gas, Group H only.
* The value is used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating of dwellings. The test data from
which it has been calculated have been certied by a notied body.
*Required for maximum ow rate. Boiler operates down to 2 l/min DHW delivery
** In areas of low water pressure the DHW restrictor can be removed
Maximum DHW Input : 26 32 40
Nett CV kW 26.1 32.1 40.2
(Btu/h) 89,100 109,500 137,200
Gross CV kW 29.0 35.6 44.6
(Btu/h) 98,800 121,600 152,200
Gas Consumption m
3
/h 2.695 3.314 4.150
(ft
3
/h) 95.2 117.1 146.6
Maximum kW 26.0 32.0 40.0
DHW Output (Btu/h) 88,700 109,200 136,500
DHW Flow Rate l/min 10.6 13.1 16.4
at 35°C temp. rise. (gpm) 2.3 2.9 3.6
DHW Specic Rate l/min 12.4 15.3 19.1
(gpm) 2.7 3.4 4.2
Boiler Input : Max. Min.
26 32 40 26 32 40
Boiler Input ‘Q’ Nett CV kW 18.1 26.1 32.1 3.7 4.6 5.7
(Btu/h) 61,800 89,100 109,500 12,700 15,600 19,500
Gross CV kW 20.1 29.0 35.6 4.1 5.1 6.3
(Btu/h) 68,500 98,800 121,600 14,100 17,300 21,600
Gas Consumption m
3
/h 1.869 2.695 3.314 0.383 0.472 0.590
(ft
3
/h) 66.0 95.2 117.1 13.6 16.7 20.8
Boiler Output :
Non Condensing kW 18.0 26.0 32.0 3.7 4.6 5.7
70
o
C Mean Water temp. (Btu/h) 61,400 88,700 109,200 12,800 15,700 19,600
Condensing kW 19.3 27.9 34.3 4.0 4.9 6.1
40
o
C Mean Water temp. (Btu/h) 65,900 95,300 117,200 13,600 16,700 20,900
Seasonal efciency* SEDBUK 2005 91.0 91.1 91.0 n/a
Seasonal efciency* SEDBUK 2009 89.1 89.2 89.1 n/a
NOx Classication Class 5
Table 2 - performance Data - Central heating
Table 3 - performance Data - Domestic hot Water
