Location 11: Tamper per Zone
Tamper is a way of monitoring a device for any type of interference, without having to use extra cable.
Tamper is always active even when the alarm is disarmed.
When enabling tamper per zone the 3k3 end of line resistor is replaced by 12K and
4K7 ohm resistors, which are placed in parallel, as can be seen in the diagram
below.
The 4K7 ohm resistor represents the zone and the 12K represents the tamper.
Note: When tamper per zone is enabled it is enabled for all the zones.
Location 12: Arming Options
These options determine how the system will arm and if the system should arm depending on two
conditions.
Quick Arm: The ability to arm the system by holding the [1] key down until the systems begins to arm.
Entry / Exit delay with arm zone: When a zone is an arm/disarm zone and a key switch or a remote receiver
transmitter are being used to arm the system.
Forced Arming: This option is to be used with much caution! This will allow the system to arm even when
there a zones violated. (Use with caution.)
Engineer Reset: If an alarm is triggered, this option will not allow the system to be armed again, until the
installer code has been entered.
Entry/Exit
delay with
arm zone
To Next Page
