1.2. Jumpers
The IDS Xwave 8 Channel Standalone Wireless Receiver has 3 jumpers that allow you
to set the supervision time, enable tamper and enable RF Jam detection.
Supervision Time is set to 3 hours.
Supervision Time is set to 24 hours.
The Supervision Time is the amount of time the receiver will wait for a supervision signal
from the detector. If no supervision signal is received a Supervision failure will be
created.
Enables RF Jam detection.
Disables RF Jam detection.
When RF Jam Detection is enabled it uses Zone output 8 when an RF jam is detected.
If RF Jam Detection is enabled then detector 8 is disabled.
The tamper button is also used to program the receiver, when programming the
receiver JP 3 must be off.
1.3. Trouble Outputs
There are 3 trouble outputs, excluding zone 8 when using RF Jam Detection. These
outputs include Tamper, Low Battery and Supervision. When the IDS Xwave 8 Channel
Standalone Wireless Receiver receives a trouble condition it will trigger the
corresponding output until it has received a restoral for that trouble.
1.4. Zone Outputs
There are 8 zone outputs numbered 1 - 8 for each learned detector, these outputs are
triggered when the receiver gets a signal from the corresponding detector. The outputs
should be wired to the zone of an alarm panel.
If RF Jam Detection is enabled then output 8 is triggered when the receiver detects an
RF jam, and will ignore any signals from detector 8.
