Configuration Value
01
iConfiguration
00
Attributes
A0
Bus power; With remote wakeup
Power
32
100 mA
Interface Descriptor: (USB-HID)
Field
Value (Hex)
Description
Length
09
Des type
04
Interface No.
00
Alternator Setting
00
# EP
02
Interface Class
03
HID
Sub Class
00
Interface Protocol
00
iInterface
00
HID Descriptor:
Field
Value (Hex)
Description
Length
09
bDescriptorType
21
HID
bcdHID(L/H)
11 01
Rev 1.11
bCountryCode
00
bNumDescriptors
01
bDescriptorType
22
Report
wDescriptorLength(L/H)
1C 00
L H
End Point Descriptor: (EP2)
Field
Value
Description
Length
07
Des Type
05
End Point
EP Addr
02
EP2 Out, Command Down
Attributes
03
Interrupt
wMaxPacketSize
40 00
64 Bytes
bInterval
04
4 milliseconds
End Point Descriptor: (EP1)
Field
Value
Description
Length
07
Des Type
05
End Point
EP Addr
81
EP1 In, Response Up
Attributes
03
Interrupt
Size
40 00
64 Bytes
Interval
04
4 milliseconds
