IDTECH Augusta - Applicable Documents and Specifications; Structure and Components; Durability and Reliability Metrics

Copyright 2019 ID TECH. All rights reserved. Document Number: 80145503-001
Page 9 of 32
4. Applicable Documents
ISO 7810 Identification cards -- Physical characteristics
ISO 7811 Identification Cards -- Tracks 1 through 3
ISO 7816 Identification cards -- Integrated circuit cards
ISO 4909 Magnetic stripe content for Track 3
EMV Contact Specifications for Payment Systems Version 4.3
5. Specifications
5.1. Structure
5.2. Durability/Reliability
No.
Item
Specification
1
Magnetic Head
1,000,000 swipes minimum
2
Rail
1,000,000 swipes minimum
3
Smartcard connector
500,000 inserts minimum
4
Drop Test
Unit is able to withstand 4 ft. drop to concrete on 6 surfaces and
4 corners (6 cycles) and remain functionally intact
5
IK Test
IK08
6
IP Test
IP50 when placed horizontal; IP52 when unit is mounted
vertical.
7
Electrostatic discharge
Electronics can survive ESD of 8kV contact, and 12kV air
discharge, with no loss of communications
8
MTBF
120,000 POH minimum
No. Item Specification Note
1
Physical Dimensions
Maximum 127mm x 52mm x 35mm
L x W x H
2
Structure Material
Plastic
3
Status LED
Tri-color LED to indicate reader status
Blue, Red, Green
4
ICC LED
Blue LEDs to indicate ICC card insertion
5
Magnetic Head
3 tracks read head
6
Head material
Permalloy
7
Slot width
1.0mm (MSR) or 0.9mm (ICC)
8
Card format
ISO-7816
9
ICC Contact force
0.2 to 0.6N
10
Battery
3.0V lithium
5 yr life
11
Beeper
75db @4KHz
