ID TECH SREDKey 2 Integration Manual
Page | 26
9.2.2. NON-ISO/ABA Data Output Format
Note:
• Field 12, 13, 14
o Financial card output is masked data.
o Non-financial card output is clear data.
• Field 22
o
The serial number is sent out with the default setting.
Field
Description
1
STX
2
Data Length
3
Card Encode Type
4
Track Status
5
Track1 data length
6
Track2 data length
7
Track3 data length
8
Clear/mask data sent status
9
Encrypted/Hash data sent status
10
Optional bytes length
11
Optional bytes
12
Track1 clear/mask data
13
Track2 clear/mask data
14
Track3 clear/mask data
15
Track1 encrypted data
16
Track2 encrypted data
17
Track3 encrypted data
18
TransactionID (Session ID for Security level 4, Terminal/Merchant ID for TransArmor)
19
Track1 hashed (if encrypted)
20
Track2 hashed (if encrypted)
21
Track3 hashed (if encrypted)
22
Reader Serial Number
23
Key ID (10 bytes KSN for DUKPT, 10 bytes Key ID for fixed key, 11 bytes Key ID for
TransArmor)
24
MAC Value length
25
MAC Value
26
KSN for MAC DUKPT
27
CheckLrc
28
CheckSum
29 ETX (0x03)
