ID TECH SREDKey 2 Integration Manual
Page | 38
17. Appendix A: Setting Configuration Parameters and Values (ITP
Protocol)
The table below describes SREDKey 2 default settings and available settings (value within
parentheses) for each function ID.
Function ID
Hex
Length
Name
Default Setting
Description
TrackSelectID 13 1
Track
Selection
‘0’ Any Track 0-any
TrackSepID 17 1
Track
Separator
0x0D=CR/Enter
CR for RS232, Enter for KB any character
supported except 00 which means none.
Sentinel and
Account number
controlID
19 1
Sentinel and
Account
number
control
‘1’
Bit0: 1- Send start/end sentinel, 0-Not send
start/end sentinel.
Bit1: 1- Only send account number on Track 2,
0-Send all data on Track 2.
Bit2: 1- Send error notification, 0-Not error
notification.
Bit3: 1- Alt Key Output, 0-Control Key Output.
MSRReadingID 1A 1
MSR Reading
Setting
‘1’ (‘0’~‘3’)
‘0’ MSR Reading Disabled.
‘1’ MSR Reading Enabled.
DecodingMethodI
D
1D 1
Decoding
Direction
‘1’ (‘0’~’3’)
Reading Direction
0x30 – Raw Data Decoding in Both Directions.
0x31 – Decode in Both directions.
0x32 – Moving Stripe Along Head in Direction
of Encoding.
0x33 – Moving Stripe Along Head Against
Direction of Encoding.
ReviewID 1F 1
Review All
Settings
None
CustSetID 30 1
Custom
Customer
Settings
04(00 - 07)
0-Level 3/4 Non-CC send as Level 1.
.1-Level3: No empty pkt when not enough
sampling bits.
.2- Enhanced Secured Output will have SN
after hash.
Track1PrefixID
34
6
Track 1 Prefix
0 (any string)
No prefix for track 1, 6 char max.
Track2PrefixID
35
6
Track 2 Prefix
0 (any string)
No prefix for track 2, 6 char max.
Track3PrefixID
36
6
Track 3 Prefix
0 (any string)
No prefix for track 3, 6 char max.
Track1SuffixID
37
6
Track 1 Suffix
0 (any string)
No suffix for track 1, 6 char max.
Track2SuffixID
38
6
Track 2 Suffix
0 (any string)
No suffix for track 2, 6 char max.
Track3SuffixID
39
6
Track 3 Suffix
0 (any string)
No suffix for track 3, 6 char max.
PrePANID 49 1
PAN to not
mask
4 (0-6) # leading PAN digits to display.
PostPANID 4A 1
PAN to not
mask
4 (0-4) # of trailing PAN digits to display.
MaskCharID 4B 1
mask the
PAN with this
character
‘*’ 20-7E Any printable character
