ID TECH SREDKey 2 Integration Manual
Page | 7
5. Base Functionality and Operations
When the SREDKey 2 is powered on it enters Data Capture Mode, prompting a user to key-in data.
If the SREDKey 2 has not been injected with a key and encryption is not enabled, it displays “Missing
Transaction Keys” after the user presses any key. Evaluation units come injected with the ID TECH
demo key by default, and data can be decrypted using ID TECH’s Universal SDK DEMO
.
5.1. Function Key Operation
• Left Arrow key Clicking the (backspace) key allows users to remove entered data one
character at a time.
• #Admin: Clicking the #Admin key when the screen displays “Swipe or Hand-Key Card
Number” or “Enter Card Number then press Enter” allows users to enter the Admin Menu.
Clicking the #Admin key in other screens puts the device in the Help Mode.
• Cancel: Clicking the Cancel key once allows the users to remove all the input in the current
and previous levels. The device then returns to the previous prompt for the current
transaction. When the Cancel key is pressed twice, the current transaction is cancelled, and
the device goes back to the initial mode.
Note: See Enabling and Disabling the SREDKey 2 Admin Key for instructions on turning the Admin
key on and off.
5.2. Admin Menu
To select one of six manual entry modes, click the Admin key and the screen will display "Select
manual config 1-6".
5.3. Manually Keyed Configuration Operations
Card Number, Expiration Date
Card Number, Expiration Date, Zip
Card Number, Expiration Date, Street Number of the Address, Zip Code
Card Number, Expiration Date, Security Code, Zip Code
Card Number, Expiration Date, Security Code, Street Number, Zip Code
Card Number, Expiration Date, Security Code
