ID TECH SREDKey 2 Integration Manual
Page | 41
Function ID
Hex
Length
Name
Default Setting
Description
KeyedOptID 8F* 1
Keyed
Options
3
bit 0: if 0: output in original keyed output; 1:
output in enhanced keyed-in output.
bit 1: if 0: allow empty CVV entry; 1: require 3
or more CVV digits.
bit 2: if 0: allow empty ZIP entry; 1: require 5
or more ZIP digits.
bit 3: if 0: allow empty ADR entry; 1: require 1
or more ADR digits.
bit 4: if 0: do mod-10 check on keyed-in PAN;
1: don’t check PAN mod-10.
bit 5: if 1: "Admin" disable; 0: "Admin" enable.
bits 6-7: reserved all zero.
Non-
fincilEncryptOptID
90* 1
Non-financial
card
encryption
options
‘0’
‘0’ non –financial card output plaintext at level
3.
‘1’ non –financial card output as financial card
at level 3.
Equip2ID AE* 1
Equip Setting
byte for
different
readers or
new settings
0(00-0xFF)
if bit4 =1 send serial number during USB
enumeration.
CustomSet3ID B0 1
Customer
Setting
0 (0, 1)
B0=0: Standard Manual entry display.
B1=1: Remise special display, in PAN entry
mode, have hyphen each 4 digits, pre-pan and
post-pan are always 4, PAN length is not
more than 16 digits, mask PAN has a short
delay after PAN data is displayed in clear text.
PrefixID
D2
15
Preamble
0 (any 15)
No Preamble, 15 character maximum.
PostfixID
D3
15
Postamble
0 (any 15)
No Postamble, 15 character maximum.
EncryptOpt2ID
D5 1
Encrypted
Option 2
output
0 (0~1)
b0=0-Encrypted without MAC; b0=1-with
MAC.
b1-b7 reserved all 0.
* These settings do not change with a default all command
